GDOT TESTING

gdot_plan-649084f395824aaebf1f5ed48132696f · Bridge

Models

Step 1 sends drawing crops, so it needs a model that can see them. Steps 2 and 3 send step 1’s readings as text — a text-only model with a large context is a fair answer there.

1Read the crops282 crops · 269 read · 1146 objects · 2583 measurementsconfigured openai/gpt-5.6-terra-pro · about 7¢ for 13 crops · default

Every cropped image from the cropping run, page by page, with what the model read off it: view, objects, measurements, notes and labels. Click a crop to see it beside its JSON.

269 of 282 crops read · 13 failed. Analysing again retries only those.

282crops269read1146objects found2583measurements912,569tokens in478,800tokens out
Page 82 crops · 2 read
item · 1216 × 1327

Other P08 R02

page 8 · other_p08_r02
Original
Other P08 R02
{
  "view": "Detail",
  "objects": [
    {
      "name": "Traffic barrier (parapet)",
      "tag": "",
      "shape": "tapered/trapezoidal cross-section",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Cross section of a bridge barrier/parapet with reinforcing bars shown; end post tapers to 0\""
    },
    {
      "name": "Vertical reinforcement bar",
      "tag": "503A",
      "shape": "bar",
      "material": "reinforced steel",
      "count": null,
      "note": "Spaced at 14\" o.c., laps with 503B a minimum of 2'-2\""
    },
    {
      "name": "Horizontal/tie reinforcement bar",
      "tag": "503B",
      "shape": "bar",
      "material": "reinforced steel",
      "count": null,
      "note": "One at each 503A"
    },
    {
      "name": "Longitudinal reinforcement bar",
      "tag": "502",
      "shape": "bar",
      "material": "reinforced steel",
      "count": 12,
      "note": "12-502 bars in barrier; see deck plan for letter designation"
    },
    {
      "name": "Drip bead",
      "tag": "",
      "shape": "triangular",
      "material": "concrete (formed)",
      "count": 1,
      "note": "3/4\" triangular drip bead, full length of bridge, both sides"
    },
    {
      "name": "Fence (post)",
      "tag": "",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Not shown in this detail, typical callout only"
    }
  ],
  "measurements": [
    {
      "label": "Lap length",
      "value": "2'-2\"",
      "unit": "ft-in",
      "appliesTo": "503A and 503B bars"
    },
    {
      "label": "Top width",
      "value": "1'-9 1/2\"",
      "unit": "ft-in",
      "appliesTo": "barrier top"
    },
    {
      "label": "Sub-width",
      "value": "8\"",
      "unit": "in",
      "appliesTo": "tapered portion at end post"
    },
    {
      "label": "Sub-width",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "barrier top segment"
    },
    {
      "label": "Clear cover",
      "value": "1 1/2\"",
      "unit": "in",
      "appliesTo": "barrier top reinforcement"
    },
    {
      "label": "Clear cover",
      "value": "3\"",
      "unit": "in",
      "appliesTo": "barrier face reinforcement"
    },
    {
      "label": "Clear cover, two sides",
      "value": "2\"",
      "unit": "in",
      "appliesTo": "503A/503B bars"
    },
    {
      "label": "Barrier height",
      "value": "3'-6\"",
      "unit": "ft-in",
      "appliesTo": "barrier"
    },
    {
      "label": "Base thickness",
      "value": "3\"",
      "unit": "in",
      "appliesTo": "barrier base / drip bead offset"
    },
    {
      "label": "Bar spacing",
      "value": "14\"",
      "unit": "in",
      "appliesTo": "503A"
    },
    {
      "label": "Bar count",
      "value": "12",
      "unit": "",
      "appliesTo": "502 bars in barrier"
    },
    {
      "label": "Drip bead size",
      "value": "3/4\"",
      "unit": "in",
      "appliesTo": "triangular drip bead"
    },
    {
      "label": "Scale",
      "value": "3/4\" = 1'-0\"",
      "unit": "",
      "appliesTo": "Barrier Detail drawing"
    }
  ],
  "notes": [
    "NOTE: LAP 503A AND 503B BARS A MINIMUM OF 2'-2\"",
    "*TAPERS TO 0\" AT END POST",
    "FENCE NOT SHOWN, TYP.",
    "503B AT EACH 503A",
    "2\" CL., TWO SIDES",
    "12-502 IN BARRIER, SEE DECK PLAN FOR LETTER DESIGNATION",
    "503A AT 14\"",
    "¾\" TRIANGULAR DRIP BEAD, FULL LENGTH OF BRIDGE BOTH SIDES"
  ],
  "labels": [
    "BARRIER DETAIL",
    "SCALE: 3/4\" = 1'-0\""
  ],
  "description": "This crop is a cross-sectional detail of a bridge concrete traffic barrier (parapet), showing its tapered profile, height, and reinforcing bar layout (503A, 503B, and 502 bars) with associated cover dimensions and spacing. Notes call out bar lap lengths, taper at the end post, cover requirements, a drip bead detail, and a reference to the deck plan for bar letter designations; fence is noted as not shown. The drawing is titled 'BARRIER DETAIL' at a scale of 3/4\" = 1'-0\"."
}

Other P08 R02

done

other_p08_r02

Detail6 objects · 13 measurements · 8 notes · 2 labels

This crop is a cross-sectional detail of a bridge concrete traffic barrier (parapet), showing its tapered profile, height, and reinforcing bar layout (503A, 503B, and 502 bars) with associated cover dimensions and spacing. Notes call out bar lap lengths, taper at the end post, cover requirements, a drip bead detail, and a reference to the deck plan for bar letter designations; fence is noted as not shown. The drawing is titled 'BARRIER DETAIL' at a scale of 3/4" = 1'-0".

Objects · 6

MarkObjectNo.ShapeMaterialNote
Traffic barrier (parapet)1tapered/trapezoidal cross-sectionreinforced concreteCross section of a bridge barrier/parapet with reinforcing bars shown; end post tapers to 0"
503AVertical reinforcement barbarreinforced steelSpaced at 14" o.c., laps with 503B a minimum of 2'-2"
503BHorizontal/tie reinforcement barbarreinforced steelOne at each 503A
502Longitudinal reinforcement bar12barreinforced steel12-502 bars in barrier; see deck plan for letter designation
Drip bead1triangularconcrete (formed)3/4" triangular drip bead, full length of bridge, both sides
Fence (post)Not shown in this detail, typical callout only

Measurements · 13

MeasurementValueUnitApplies to
Lap length2'-2"ft-in503A and 503B bars
Top width1'-9 1/2"ft-inbarrier top
Sub-width8"intapered portion at end post
Sub-width1'-0"ft-inbarrier top segment
Clear cover1 1/2"inbarrier top reinforcement
Clear cover3"inbarrier face reinforcement
Clear cover, two sides2"in503A/503B bars
Barrier height3'-6"ft-inbarrier
Base thickness3"inbarrier base / drip bead offset
Bar spacing14"in503A
Bar count12502 bars in barrier
Drip bead size3/4"intriangular drip bead
Scale3/4" = 1'-0"Barrier Detail drawing

Labels

BARRIER DETAILSCALE: 3/4" = 1'-0"

Notes

  • NOTE: LAP 503A AND 503B BARS A MINIMUM OF 2'-2"
  • *TAPERS TO 0" AT END POST
  • FENCE NOT SHOWN, TYP.
  • 503B AT EACH 503A
  • 2" CL., TWO SIDES
  • 12-502 IN BARRIER, SEE DECK PLAN FOR LETTER DESIGNATION
  • 503A AT 14"
  • ¾" TRIANGULAR DRIP BEAD, FULL LENGTH OF BRIDGE BOTH SIDES

anthropic/claude-sonnet-5 · 4975 tokens · 17.2s
