Deck Slab

{
  "view": "Plan",
  "objects": [
    {
      "name": "bent",
      "tag": "BENT 1 (B.F.P.R. BENT 1L/1R)",
      "shape": "",
      "material": "reinforced concrete",
      "count": 1,
      "note": "end bent, front face of wall 1, expansion/fixed bearings noted"
    },
    {
      "name": "bent",
      "tag": "BENT 2 (BENT 2L/2R)",
      "shape": "",
      "material": "reinforced concrete",
      "count": 1,
      "note": "interior bent, fixed bearings"
    },
    {
      "name": "bent",
      "tag": "BENT 3 (BENT 3L/3R)",
      "shape": "",
      "material": "reinforced concrete",
      "count": 1,
      "note": "interior bent, expansion bearings"
    },
    {
      "name": "bent",
      "tag": "BENT 4 (B.F.P.R. BENT 4L/4R)",
      "shape": "",
      "material": "reinforced concrete",
      "count": 1,
      "note": "end bent, front face of wall 2, expansion bearings"
    },
    {
      "name": "wingwall/wall",
      "tag": "WALL 1",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 2,
      "note": "front face of wall 1, appears at both ends of left/right bridge"
    },
    {
      "name": "wingwall/wall",
      "tag": "WALL 2",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 2,
      "note": "front face of wall 2"
    },
    {
      "name": "bearing",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 8,
      "note": "marked EXP. and FIX at bent locations in elevation view"
    },
    {
      "name": "pile bent support",
      "tag": "",
      "shape": "pile group/footing",
      "material": "reinforced concrete",
      "count": 2,
      "note": "shown schematically under bents 2 and 3 in elevation"
    },
    {
      "name": "chain link wire fence",
      "tag": "",
      "shape": "linear",
      "material": "chain link/metal",
      "count": 3,
      "note": "typical, shown at deck level in elevation"
    },
    {
      "name": "deck/superstructure",
      "tag": "LEFT BRIDGE / RIGHT BRIDGE",
      "shape": "rectangular/trapezoidal in plan",
      "material": "reinforced concrete",
      "count": 2,
      "note": "twin parallel bridge structures (left and right) crossing railroad"
    },
    {
      "name": "railroad track",
      "tag": "CENTRAL OF GEORGIA RAILROAD COMPANY EXISTING TRACK",
      "shape": "linear",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "future track",
      "tag": "FUTURE TRACK",
      "shape": "linear",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "future access road",
      "tag": "FUTURE ACCESS ROAD",
      "shape": "linear",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "temporary shoring",
      "tag": "",
      "shape": "linear",
      "material": "",
      "count": 1,
      "note": "as necessary, typical, near end bridge"
    }
  ],
  "measurements": [
    {
      "label": "Total length of bridge",
      "value": "192'-0\"",
      "unit": "ft-in",
      "appliesTo": "bridge overall"
    },
    {
      "label": "Span 1 length",
      "value": "55'-0\"",
      "unit": "ft-in",
      "appliesTo": "Bent 1 to Bent 2"
    },
    {
      "label": "Span 2 length",
      "value": "82'-0\"",
      "unit": "ft-in",
      "appliesTo": "Bent 2 to Bent 3"
    },
    {
      "label": "Span 3 length",
      "value": "55'-0\"",
      "unit": "ft-in",
      "appliesTo": "Bent 3 to Bent 4"
    },
    {
      "label": "Out to out width",
      "value": "43'-7\"",
      "unit": "ft-in",
      "appliesTo": "bridge deck"
    },
    {
      "label": "Gutter to gutter width",
      "value": "40'-0\"",
      "unit": "ft-in",
      "appliesTo": "bridge deck"
    },
    {
      "label": "Skew angle",
      "value": "81°-20'-05.0\"",
      "unit": "deg-min-sec",
      "appliesTo": "typical bent skew"
    },
    {
      "label": "Bearing offset",
      "value": "1'-9 1/2\"",
      "unit": "ft-in",
      "appliesTo": ""
    },
    {
      "label": "Dimension",
      "value": "6'-0\"",
      "unit": "ft-in",
      "appliesTo": "multiple locations near point of min vert clearance"
    },
    {
      "label": "Dimension",
      "value": "34'-0\"",
      "unit": "ft-in",
      "appliesTo": "Bent 3L/3R area"
    },
    {
      "label": "Dimension",
      "value": "22'-0\"",
      "unit": "ft-in",
      "appliesTo": "near end bridge station"
    },
    {
      "label": "Elevation",
      "value": "EL. 151.00",
      "unit": "ft",
      "appliesTo": "typical elevation reference at bents 2 and 3"
    },
    {
      "label": "Station",
      "value": "STA. 17+23.00",
      "unit": "",
      "appliesTo": "Begin Bridge"
    },
    {
      "label": "Station",
      "value": "STA. 17+29.07",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "Station",
      "value": "STA. 18+16.85",
      "unit": "",
      "appliesTo": "CL SR 21"
    },
    {
      "label": "Station",
      "value": "STA. 303+80.83",
      "unit": "",
      "appliesTo": "CL Central of Georgia Railroad Company"
    },
    {
      "label": "Station",
      "value": "STA. 19+08.93",
      "unit": "",
      "appliesTo": "CL SR 21 / PT#3"
    },
    {
      "label": "Station",
      "value": "STA. 19+15.00",
      "unit": "",
      "appliesTo": "End Bridge"
    },
    {
      "label": "Bearing/angle",
      "value": "N 2°-23'-16.7\" E",
      "unit": "deg-min-sec",
      "appliesTo": "future track alignment"
    },
    {
      "label": "Bearing/angle",
      "value": "N 83°-43'-21.7\" E",
      "unit": "deg-min-sec",
      "appliesTo": "SR 21 alignment"
    },
    {
      "label": "Distance",
      "value": "75'-10 5/16\"",
      "unit": "ft-in",
      "appliesTo": "future track clearance dimension"
    },
    {
      "label": "Distance",
      "value": "74'-7 5/16\"",
      "unit": "ft-in",
      "appliesTo": "existing track clearance dimension"
    },
    {
      "label": "Minimum clearance",
      "value": "12'-1\"",
      "unit": "ft-in",
      "appliesTo": "CL Central of Georgia Railroad existing track, min"
    },
    {
      "label": "Minimum clearance",
      "value": "14'-1\"",
      "unit": "ft-in",
      "appliesTo": "right bridge, min"
    },
    {
      "label": "Minimum horizontal clearance",
      "value": "36'-4\"",
      "unit": "ft-in",
      "appliesTo": "calculated to face of column, left bridge"
    },
    {
      "label": "Minimum horizontal clearance",
      "value": "25'-8\"",
      "unit": "ft-in",
      "appliesTo": "calculated to face of column, right bridge"
    },
    {
      "label": "Dimension",
      "value": "15'-0\"",
      "unit": "ft-in",
      "appliesTo": "twice, near min horiz clearance callouts"
    },
    {
      "label": "RRMP designation",
      "value": "D-0080.54",
      "unit": "",
      "appliesTo": "railroad milepost marker"
    }
  ],
  "notes": [
    "ALL BENTS ARE F... RAILWAY COMPANY... (text cut off, partial)",
    "END BENT PILES ... (text cut off, partial)",
    "STATIONS ARE AL... AND B.F.P.R. OR ... ELEVATIONS ARE ... PROFILE GRADE LI... PROFILE GRADE LI... (text cut off, partial)",
    "MEASURED ALONG... (text cut off, partial)",
    "LEFT BRIDGE: MINIMUM REQUIRED... EXISTING TRACK V... FUTURE TRACK VE... RIGHT BRIDGE: MINIMUM REQUIRED... EXISTING TRACK V... FUTURE TRACK VE... (text cut off, partial)",
    "MINIMUM REQUIRED... (text cut off, partial)",
    "TEMPORARY SHORING AS NECESSARY, TYP.",
    "TO BE REMOVED",
    "APPROXIMATE EXISTING GROUNDLINE",
    "FUTURE GROUNDLINE"
  ],
  "labels": [
    "PLAN",
    "ELEVATION",
    "FRONT FACE OF WALL 1",
    "FRONT FACE OF WALL 2",
    "FRONT FACE OF WALL NO. 1",
    "FRONT FACE OF WALL NO. 2",
    "PGL WESTBOUND",
    "PGL EASTBOUND",
    "PGL",
    "CL BENT 2L",
    "CL BENT 3L",
    "CL BENT 2R",
    "CL BENT 3R",
    "B.F.P.R. BENT 1L",
    "B.F.P.R. BENT 4L",
    "B.F.P.R. BENT 1R",
    "B.F.P.R. BENT 4R",
    "B.F.P.R. BENT 1",
    "B.F.P.R. BENT 4",
    "BENT 2",
    "BENT 3",
    "BEGIN BRIDGE",
    "END BRIDGE",
    "CL CENTRAL OF GEORGIA RAILROAD COMPANY EXISTING TRACK",
    "CL FUTURE ACCESS ROAD",
    "CL FUTURE TRACK",
    "CL EXISTING TRACK",
    "CL SR 21",
    "TO US 25/SR 121",
    "TO GA HIGHWAY 23",
    "TO PERKINS",
    "TO MILLEN",
    "RR R/W",
    "PT #3",
    "AHEAD",
    "N.",
    "LOCATION",
    "LEFT BRI...",
    "RIGHT BRI...",
    "NOTES:",
    "CHAIN LINK WIRE FENCE, TYP.",
    "POINT OF MIN. VERT. CLEARANCE",
    "FUTURE POINT OF MIN. VERT. CLEARANCE",
    "GUTTER TO GUTTER",
    "OUT TO OUT",
    "MIN. HORIZ. CL. CALCULATED TO FACE OF COLUMN",
    "EXP.",
    "FIX",
    "EL. 151.00, TYP."
  ],
  "description": "This crop shows a combined Plan and Elevation of a twin (left and right parallel) roadway bridge structure crossing an existing and future railroad track alignment plus a future access road, at the intersection with SR 21. The plan view details bent locations (Bents 1-4, each split into L/R for the two parallel bridges), skew angles, wall/wingwall faces, minimum vertical and horizontal clearances to the tracks, and various stationing/bearing callouts; the elevation view below shows the four bents with bearing types (EXP/FIX), span lengths (55'-82'-55' totaling 192'-0\"), chain link fencing, and existing/future groundline references. A partially visible notes/table block at bottom right lists general notes and a location table for left/right bridge clearances, but this text is cut off in the crop."
}

{
  "view": "Plan",
  "objects": [
    {
      "name": "Bent",
      "tag": "1 (B.F.P.R. BENT 1)",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Also shown as BENT 1L/1R centerline reference in plan; expansion bearing per elevation"
    },
    {
      "name": "Bent",
      "tag": "2 (BENT 2L/2R)",
      "shape": "tapered/skewed",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Fixed bearing per elevation; pile bent shown in elevation with visible pile group"
    },
    {
      "name": "Bent",
      "tag": "3 (BENT 3L/3R)",
      "shape": "tapered/skewed",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Fixed/expansion bearings shown in elevation"
    },
    {
      "name": "Bent",
      "tag": "4 (B.F.P.R. BENT 4)",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Expansion bearing per elevation"
    },
    {
      "name": "Wingwall/Retaining Wall",
      "tag": "WALL 1",
      "shape": "rectangular",
      "material": "",
      "count": 2,
      "note": "Front face of Wall 1 shown at both bridges (left and right)"
    },
    {
      "name": "Wingwall/Retaining Wall",
      "tag": "WALL 2",
      "shape": "rectangular",
      "material": "",
      "count": 2,
      "note": "Front face of Wall 2 shown at both bridges"
    },
    {
      "name": "Pile",
      "tag": "",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Shown schematically under Bent 2 and Bent 3 in elevation view"
    },
    {
      "name": "Bearing",
      "tag": "EXP",
      "shape": "",
      "material": "",
      "count": 4,
      "note": "Expansion bearings at Bent 1, Bent 3, Bent 4 (multiple locations) per elevation"
    },
    {
      "name": "Bearing",
      "tag": "FIX",
      "shape": "",
      "material": "",
      "count": 2,
      "note": "Fixed bearings at Bent 2 per elevation"
    },
    {
      "name": "Chain link wire fence",
      "tag": "",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Typical, shown atop deck in elevation at two locations"
    },
    {
      "name": "Temporary shoring",
      "tag": "",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Called out as necessary, typical, near end bridge station"
    },
    {
      "name": "Deck/Superstructure",
      "tag": "",
      "shape": "rectangular in plan",
      "material": "",
      "count": 1,
      "note": "Shown in plan with gutter-to-gutter and out-to-out dimensions; PGL Eastbound/Westbound labeled"
    }
  ],
  "measurements": [
    {
      "label": "MIN clearance to existing track",
      "value": "12'-1\"",
      "unit": "",
      "appliesTo": "Central of Georgia Railroad existing track"
    },
    {
      "label": "Distance",
      "value": "74'-7 5/16\"",
      "unit": "",
      "appliesTo": "Point of Min. Vert. Clearance"
    },
    {
      "label": "Distance",
      "value": "75'-10 5/16\"",
      "unit": "",
      "appliesTo": "Future Point of Min. Vert. Clearance"
    },
    {
      "label": "Bearing angle",
      "value": "N 2°-23'-16.7\" E",
      "unit": "",
      "appliesTo": "Future Access Road alignment"
    },
    {
      "label": "Offset",
      "value": "1'-9 1/2\"",
      "unit": "",
      "appliesTo": "Point of Min. Vert. Clearance offsets (multiple)"
    },
    {
      "label": "Offset",
      "value": "6'-0\"",
      "unit": "",
      "appliesTo": "Point/Future Point of Min. Vert. Clearance offsets (multiple)"
    },
    {
      "label": "Gutter to gutter width",
      "value": "40'-0\"",
      "unit": "",
      "appliesTo": "Bridge deck (Bent 2L/2R area)"
    },
    {
      "label": "Out to out width",
      "value": "43'-7\"",
      "unit": "",
      "appliesTo": "Bridge deck"
    },
    {
      "label": "Distance",
      "value": "34'-0\"",
      "unit": "",
      "appliesTo": "Bent 3L/3R region"
    },
    {
      "label": "Skew angle",
      "value": "81°-20'-05.0\"",
      "unit": "",
      "appliesTo": "Bent skew, typical, multiple bents"
    },
    {
      "label": "Station",
      "value": "STA. 18+16.85",
      "unit": "",
      "appliesTo": "Ç SR 21"
    },
    {
      "label": "Station",
      "value": "STA. 303+80.83",
      "unit": "",
      "appliesTo": "Ç Central of Georgia Railroad Company"
    },
    {
      "label": "Station",
      "value": "STA. 17+23.00",
      "unit": "",
      "appliesTo": "Begin Bridge"
    },
    {
      "label": "Station",
      "value": "STA. 17+29.07",
      "unit": "",
      "appliesTo": ""
    },
    {
      "label": "Station",
      "value": "STA. 19+08.93",
      "unit": "",
      "appliesTo": "PT#3"
    },
    {
      "label": "Station",
      "value": "STA. 19+15.00",
      "unit": "",
      "appliesTo": "End Bridge"
    },
    {
      "label": "Bearing angle",
      "value": "N 83°-43'-21.7\" E",
      "unit": "",
      "appliesTo": "Ç SR 21"
    },
    {
      "label": "Distance",
      "value": "22'-0\"",
      "unit": "",
      "appliesTo": "unlabeled dimension near Bent 3 area"
    },
    {
      "label": "Distance",
      "value": "15'-0\"",
      "unit": "",
      "appliesTo": "unlabeled dimension (two instances) near Min Horiz Cl callout"
    },
    {
      "label": "Min. Horiz. Cl.",
      "value": "25'-8\"",
      "unit": "",
      "appliesTo": "calculated to face of column"
    },
    {
      "label": "Min. Horiz. Cl.",
      "value": "36'-4\"",
      "unit": "",
      "appliesTo": "calculated to face of column"
    },
    {
      "label": "MIN clearance",
      "value": "14'-1\"",
      "unit": "",
      "appliesTo": "unlabeled feature near Wall 2"
    },
    {
      "label": "Total length of bridge",
      "value": "192'-0\"",
      "unit": "",
      "appliesTo": "Bridge overall"
    },
    {
      "label": "Span length",
      "value": "55'-0\"",
      "unit": "",
      "appliesTo": "End spans (Bent1-2 and Bent3-4)"
    },
    {
      "label": "Span length",
      "value": "82'-0\"",
      "unit": "",
      "appliesTo": "Middle span (Bent2-3)"
    },
    {
      "label": "Elevation",
      "value": "151.00",
      "unit": "",
      "appliesTo": "Typical elevation callout near bent piles"
    }
  ],
  "notes": [
    "TO US 25/SR 121",
    "TO GA HIGHWAY 23",
    "TO PERKINS",
    "TO MILLEN",
    "AHEAD",
    "BEGIN BRIDGE",
    "END BRIDGE",
    "TEMPORARY SHORING AS NECESSARY, TYP.",
    "TO BE REMOVED",
    "RR R/W",
    "FRONT FACE OF WALL 1",
    "FRONT FACE OF WALL 2",
    "PGL WESTBOUND",
    "PGL EASTBOUND",
    "RRMP D-0080.54",
    "CHAIN LINK WIRE FENCE, TYP.",
    "FUTURE GROUNDLINE",
    "APPROXIMATE EXISTING GROUNDLINE",
    "EXP.",
    "FIX"
  ],
  "labels": [
    "PLAN",
    "ELEVATION",
    "Ç FUTURE ACCESS ROAD",
    "Ç FUTURE TRACK",
    "Ç CENTRAL OF GEORGIA RAILROAD COMPANY EXISTING TRACK",
    "Ç EXISTING TRACK",
    "Ç SR 21",
    "Ç BENT 2L",
    "Ç BENT 3L",
    "Ç BENT 2R",
    "Ç BENT 3R",
    "B.F.P.R. BENT 1L",
    "B.F.P.R. BENT 1R",
    "B.F.P.R. BENT 4L",
    "B.F.P.R. BENT 4R",
    "BENT 2",
    "BENT 3",
    "B.F.P.R. BENT 1",
    "B.F.P.R. BENT 4",
    "N."
  ],
  "description": "This crop presents a combined Plan and partial Elevation of a twin bridge structure (Left Bridge and Right Bridge) crossing a railroad and future access road at a skewed angle, with Bents 1 through 4 identified. The plan shows deck geometry, clearance envelopes (point of minimum vertical clearance, existing and future), stationing along SR 21 and the railroad centerline, and horizontal/vertical clearance callouts; the elevation below shows bent locations, bearing types (EXP/FIX), pile schematics at Bents 2 and 3, fencing, and groundline references. A partial schedule table and general notes referenced elsewhere on the sheet govern clearance minimums and station/elevation measurement conventions but are not reproduced here."
}

{
  "view": "Notes",
  "objects": [
    {
      "name": "deck slab",
      "tag": "",
      "shape": "",
      "material": "grooved concrete",
      "count": null,
      "note": "Bridge deck surface requiring transverse grooving"
    },
    {
      "name": "fence",
      "tag": "",
      "shape": "",
      "material": "chain link, zinc coated",
      "count": null,
      "note": "6FT height, 9 GA wire, paid per linear foot"
    }
  ],
  "measurements": [
    {
      "label": "Fence height",
      "value": "6",
      "unit": "FT",
      "appliesTo": "chain link fence"
    },
    {
      "label": "Wire gauge",
      "value": "9",
      "unit": "GA",
      "appliesTo": "chain link fence"
    }
  ],
  "notes": [
    "GROOVED CONCRETE - GROOVE THE ENTIRE LENGTH OF THE BRIDGE TRANSVERSELY AS PER SUB-SECTION 500.3.05.T.9.C. OF THE GEORGIA DOT SPECIFICATIONS. PROVIDE GROOVING BEFORE PLACING TRAFFIC ON DECK.",
    "CHAIN LINK FENCE - CHAIN LINK FENCE SHALL BE PAID FOR AS \"LF CH LK FENCE, ZC COAT, 6FT, 9 GA.\""
  ],
  "labels": [],
  "description": "This crop contains two general construction notes from a bridge drawing sheet. The first note specifies grooving requirements for the bridge deck concrete per Georgia DOT specifications, and the second specifies the payment description for chain link fence including coating, height, and gauge. No plan, section, or schedule graphics are present in this crop."
}

{
  "view": "Notes",
  "objects": [
    {
      "name": "Bridge deck",
      "tag": "",
      "shape": "",
      "material": "concrete",
      "count": null,
      "note": "Referenced in grooved concrete note"
    },
    {
      "name": "Chain link fence",
      "tag": "",
      "shape": "",
      "material": "galvanized/zinc coated steel",
      "count": null,
      "note": "Referenced in fencing note"
    }
  ],
  "measurements": [
    {
      "label": "Chain link fence height",
      "value": "6",
      "unit": "FT",
      "appliesTo": "Chain link fence"
    },
    {
      "label": "Chain link fence gauge",
      "value": "9",
      "unit": "GA",
      "appliesTo": "Chain link fence"
    }
  ],
  "notes": [
    "GROOVED CONCRETE - GROOVE THE ENTIRE LENGTH OF THE BRIDGE TRANSVERSELY AS PER SUB-SECTION 500.3.05.T.9.C. OF THE GEORGIA DOT SPECIFICATIONS. PROVIDE GROOVING BEFORE PLACING TRAFFIC ON DECK.",
    "CHAIN LINK FENCE - CHAIN LINK FENCE SHALL BE PAID FOR AS \"LF CH LK FENCE, ZC COAT, 6FT, 9 GA.\"",
    "WELDING - ... WELDING ON GEORGIA DOT PROJECTS SHALL BE PERFORMED BY ... (text cut off at bottom of crop)"
  ],
  "labels": [],
  "description": "This crop contains a block of general construction notes from a bridge project specification sheet, covering requirements for grooved concrete deck finishing per Georgia DOT sub-section 500.3.05.T.9.C., and payment terms for chain link fencing (6FT, 9 GA, zinc coated). A third note beginning 'WELDING' is cut off at the bottom of the crop and only partially legible."
}

{
  "view": "Plan",
  "objects": [
    {
      "name": "Beam",
      "tag": "BEAM 1-6 (Westbound span)",
      "shape": "linear/I-shaped (beam line)",
      "material": "precast concrete (implied by 400A callout)",
      "count": 6,
      "note": "Centerlines shown as dash-dot lines, beams 1 through 6 for westbound deck"
    },
    {
      "name": "Beam",
      "tag": "BEAM 7-12 (Eastbound span)",
      "shape": "linear/I-shaped (beam line)",
      "material": "precast concrete (implied by 400A callout)",
      "count": 6,
      "note": "Centerlines shown as dash-dot lines, beams 7 through 12 for eastbound deck"
    },
    {
      "name": "Diaphragm",
      "tag": "400A",
      "shape": "rectangular strip, perpendicular to beams",
      "material": "reinforced concrete",
      "count": 3,
      "note": "Labeled '10\" CONCRETE DIAPHRAGM, TYP.', shown crossing beams at intervals, callout '400A' repeated twice (once per span)"
    },
    {
      "name": "Edgebeam",
      "tag": "",
      "shape": "linear strip along deck edge",
      "material": "concrete",
      "count": 2,
      "note": "1'-0\" EDGEBEAM, TYP., one along each side of each span"
    },
    {
      "name": "Fillet",
      "tag": "",
      "shape": "linear strip",
      "material": "concrete",
      "count": 4,
      "note": "8\" FILLET, TYP., shown along beam edges"
    },
    {
      "name": "Endwall",
      "tag": "",
      "shape": "linear/rectangular",
      "material": "concrete",
      "count": 4,
      "note": "Two types called out: '3'-0\" ENDWALL OUTSIDE EXTERIOR BEAM, TYP.' and '1'-6\" ENDWALL'"
    },
    {
      "name": "Paving rest",
      "tag": "",
      "shape": "ledge/rectangular",
      "material": "concrete",
      "count": 2,
      "note": "12\" PAVING REST, TYP., one per span at bent location"
    },
    {
      "name": "Bent",
      "tag": "BENT 1 (B.F.P.R. BENT 1)",
      "shape": "not fully shown, referenced at edge of plan",
      "material": "concrete",
      "count": 2,
      "note": "Labeled 'B.F.P.R. BENT 1' appears at both spans, likely 'Back Face Paving Rest' or bent reference; only tag visible, structure not detailed in this crop"
    },
    {
      "name": "Fence post",
      "tag": "12-502A / 12-502B / 12-502C",
      "shape": "circular (post markers shown as small circles)",
      "material": "not stated",
      "count": 9,
      "note": "Fence post spacing marks along top and bottom edges of both spans, tagged 502A, 502B, 502C with quantity prefix '12-'"
    },
    {
      "name": "Deck slab",
      "tag": "",
      "shape": "rectangular/trapezoidal (skewed)",
      "material": "reinforced concrete",
      "count": 2,
      "note": "Two deck panels shown, Westbound and Eastbound, both skewed at 81°-20'-05.0\""
    }
  ],
  "measurements": [
    {
      "label": "Overall deck width (top span)",
      "value": "55'-0\"",
      "unit": "ft-in",
      "appliesTo": "Westbound deck top edge"
    },
    {
      "label": "Segment width",
      "value": "18'-4\"",
      "unit": "ft-in",
      "appliesTo": "Westbound deck top edge (3 segments)"
    },
    {
      "label": "Beam spacing",
      "value": "9'-6\"",
      "unit": "ft-in",
      "appliesTo": "Westbound deck top edge beam spacing (5 instances)"
    },
    {
      "label": "End segment",
      "value": "6'-6\"",
      "unit": "ft-in",
      "appliesTo": "Westbound deck top edge end segment"
    },
    {
      "label": "Edge offset",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "Westbound deck top edge start offset"
    },
    {
      "label": "Gutter to gutter width",
      "value": "40'-0\"",
      "unit": "ft-in",
      "appliesTo": "Deck cross width, both spans"
    },
    {
      "label": "Out to out width",
      "value": "43'-7\"",
      "unit": "ft-in",
      "appliesTo": "Deck cross width, both spans"
    },
    {
      "label": "Offset from gutter to out",
      "value": "1'-9 1/2\"",
      "unit": "ft-in",
      "appliesTo": "Deck edge, both spans (4 instances)"
    },
    {
      "label": "Fence post spacing width",
      "value": "5'-0\"",
      "unit": "ft-in",
      "appliesTo": "Fence posts near edgebeam ends, both spans (4 instances)"
    },
    {
      "label": "Skew angle",
      "value": "81°-20'-05.0\"",
      "unit": "degrees-min-sec",
      "appliesTo": "Beam skew / construction centerline skew, multiple callouts"
    },
    {
      "label": "Bearing",
      "value": "N 83°-43'-21.7\" E",
      "unit": "bearing",
      "appliesTo": "Construction reference line between spans"
    },
    {
      "label": "Fillet thickness",
      "value": "8\"",
      "unit": "in",
      "appliesTo": "Fillet, typ."
    },
    {
      "label": "Diaphragm thickness",
      "value": "10\"",
      "unit": "in",
      "appliesTo": "Concrete diaphragm, typ."
    },
    {
      "label": "Edgebeam width",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "Edgebeam, typ."
    },
    {
      "label": "Endwall thickness (exterior)",
      "value": "3'-0\"",
      "unit": "ft-in",
      "appliesTo": "Endwall outside exterior beam, typ."
    },
    {
      "label": "Endwall thickness (interior)",
      "value": "1'-6\"",
      "unit": "ft-in",
      "appliesTo": "Endwall"
    },
    {
      "label": "Paving rest width",
      "value": "12\"",
      "unit": "in",
      "appliesTo": "Paving rest"
    },
    {
      "label": "Bottom span width dimension set",
      "value": "22'-0\"",
      "unit": "ft-in",
      "appliesTo": "Vertical dimension between spans (2 instances)"
    },
    {
      "label": "Lower fence post spacing overall (bottom of westbound)",
      "value": "52'-2 13/16\"",
      "unit": "ft-in",
      "appliesTo": "Westbound deck bottom edge overall"
    },
    {
      "label": "Segment dimension",
      "value": "17'-4 5/16\"",
      "unit": "ft-in",
      "appliesTo": "Westbound deck bottom edge segment"
    },
    {
      "label": "Segment dimension",
      "value": "17'-5 1/4\"",
      "unit": "ft-in",
      "appliesTo": "Westbound deck bottom edge segment (2 instances)"
    },
    {
      "label": "End post dimension",
      "value": "4'-3\"",
      "unit": "ft-in",
      "appliesTo": "End post, westbound bottom edge"
    },
    {
      "label": "Fence post spacing segments (bottom westbound)",
      "value": "8'-9\", 8'-9\", 8'-0\", 9'-6\", 9'-6\", 6'-8 13/16\"",
      "unit": "ft-in",
      "appliesTo": "Westbound bottom edge fence post spacing"
    },
    {
      "label": "Offset",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "Westbound bottom edge start offset"
    },
    {
      "label": "Eastbound top edge overall",
      "value": "51'-8 3/8\"",
      "unit": "ft-in",
      "appliesTo": "Eastbound deck top edge overall"
    },
    {
      "label": "Segment dimension",
      "value": "17'-2 13/16\"",
      "unit": "ft-in",
      "appliesTo": "Eastbound deck top edge segment (2 instances)"
    },
    {
      "label": "Segment dimension",
      "value": "17'-2 3/4\"",
      "unit": "ft-in",
      "appliesTo": "Eastbound deck top edge segment"
    },
    {
      "label": "End post dimension",
      "value": "4'-6\"",
      "unit": "ft-in",
      "appliesTo": "End post, eastbound top edge"
    },
    {
      "label": "Fence post spacing segments (top eastbound)",
      "value": "8'-9\", 8'-9\", 8'-0\", 9'-6\", 9'-6\", 6'-2 3/8\"",
      "unit": "ft-in",
      "appliesTo": "Eastbound top edge fence post spacing"
    },
    {
      "label": "Offset",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "Eastbound top edge start offset"
    },
    {
      "label": "Overall deck width (bottom span)",
      "value": "55'-0\"",
      "unit": "ft-in",
      "appliesTo": "Eastbound deck bottom edge"
    },
    {
      "label": "Segment width",
      "value": "18'-4\"",
      "unit": "ft-in",
      "appliesTo": "Eastbound deck bottom edge (3 segments)"
    },
    {
      "label": "Beam spacing",
      "value": "9'-6\"",
      "unit": "ft-in",
      "appliesTo": "Eastbound deck bottom edge beam spacing (5 instances)"
    },
    {
      "label": "End segment",
      "value": "6'-6\"",
      "unit": "ft-in",
      "appliesTo": "Eastbound deck bottom edge end segment"
    },
    {
      "label": "Offset",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "Eastbound deck bottom edge start offset"
    }
  ],
  "notes": [
    "3'-0\" ENDWALL OUTSIDE EXTERIOR BEAM, TYP.",
    "8\" FILLET, TYP.",
    "B.F.P.R. BENT 1",
    "12\" PAVING REST",
    "1'-6\" ENDWALL",
    "1'-0\" EDGEBEAM, TYP.",
    "10\" CONCRETE DIAPHRAGM, TYP.",
    "81°-20'-05.0\", TYP.",
    "CONSTRUCTION CL SR 21",
    "81°-20'-05.0\"",
    "FENCE POST SPACING",
    "END POST"
  ],
  "labels": [
    "DECK PLAN",
    "SPAN 1",
    "PGL WESTBOUND",
    "PGL EASTBOUND",
    "12-502A",
    "12-502B",
    "12-502C",
    "400A",
    "N 83°-43'-21.7\" E",
    "aruna sastry",
    "5/31/2025",
    "11:05:27 AM"
  ],
  "description": "This crop is a Deck Plan (Span 1) for a two-span bridge structure, showing separate westbound and eastbound decks in plan view, each skewed at 81°-20'-05.0\". It details beam centerlines (Beam 1-12), fence post spacing and tags (502A/B/C), edgebeams, fillets, endwalls, paving rests, concrete diaphragms (400A), and overall/segment dimensions for deck width, gutter-to-gutter and out-to-out widths, plus a construction centerline (SR 21) and bearing reference between the two spans."
}

{
  "view": "Plan",
  "objects": [
    {
      "name": "Deck slab",
      "tag": "SPAN 1",
      "shape": "trapezoidal (skewed)",
      "material": "reinforced concrete",
      "count": 2,
      "note": "One deck plan shown for each bridge (westbound and eastbound), both labeled Span 1"
    },
    {
      "name": "Beam",
      "tag": "BEAM 1–BEAM 12",
      "shape": "longitudinal, parallel",
      "material": "precast/prestressed concrete (implied by beam callouts, not stated)",
      "count": 12,
      "note": "Six beams shown per bridge, centerlines labeled CL BEAM 1 through CL BEAM 12"
    },
    {
      "name": "Endwall",
      "tag": "",
      "shape": "linear, at ends of span",
      "material": "concrete",
      "count": 4,
      "note": "Two sizes noted: 3'-0\" endwall outside exterior beam (typ.) and 1'-6\" endwall"
    },
    {
      "name": "Edgebeam",
      "tag": "",
      "shape": "linear, along deck edge",
      "material": "concrete",
      "count": 2,
      "note": "1'-0\" edgebeam, typ., one per bridge"
    },
    {
      "name": "Diaphragm",
      "tag": "",
      "shape": "transverse, rectangular",
      "material": "concrete",
      "count": 6,
      "note": "10\" concrete diaphragm, typ.; three transverse lines shown per bridge deck"
    },
    {
      "name": "Paving rest",
      "tag": "",
      "shape": "linear ledge",
      "material": "concrete",
      "count": 2,
      "note": "12\" paving rest, one per bridge at bent end"
    },
    {
      "name": "Bent",
      "tag": "B.F.P.R. BENT 1",
      "shape": "",
      "material": "",
      "count": 2,
      "note": "Referenced as back face of bent (B.F.P.R.), one per bridge deck plan"
    },
    {
      "name": "End post",
      "tag": "END POST",
      "shape": "",
      "material": "concrete",
      "count": 2,
      "note": "Located at the skewed end of each span, dimensioned 4'-3\" and 4'-6\""
    },
    {
      "name": "Reinforcement bar",
      "tag": "12-502A",
      "shape": "bar, transverse",
      "material": "reinforcing steel",
      "count": 6,
      "note": "Shown at top and bottom edges of both bridge decks"
    },
    {
      "name": "Reinforcement bar",
      "tag": "12-502B",
      "shape": "bar, transverse",
      "material": "reinforcing steel",
      "count": 3,
      "note": "Shown along lower edge of upper (westbound) deck"
    },
    {
      "name": "Reinforcement bar",
      "tag": "12-502C",
      "shape": "bar, transverse",
      "material": "reinforcing steel",
      "count": 3,
      "note": "Shown along upper edge of lower (eastbound) deck"
    },
    {
      "name": "Reinforcement bar",
      "tag": "400A",
      "shape": "bar, longitudinal",
      "material": "reinforcing steel",
      "count": 2,
      "note": "Labeled once per deck, appears to run along beam lines"
    }
  ],
  "measurements": [
    {
      "label": "Overall deck width",
      "value": "55'-0\"",
      "unit": "ft-in",
      "appliesTo": "Span 1 deck (both bridges)"
    },
    {
      "label": "Panel spacing",
      "value": "18'-4\"",
      "unit": "ft-in",
      "appliesTo": "Deck panel spacing, repeated 3x per deck"
    },
    {
      "label": "Bar spacing",
      "value": "9'-6\"",
      "unit": "ft-in",
      "appliesTo": "12-502A/B/C bar spacing, repeated multiple times"
    },
    {
      "label": "End spacing",
      "value": "6'-6\"",
      "unit": "ft-in",
      "appliesTo": "Fence post spacing at deck end"
    },
    {
      "label": "Edge offset",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "Deck edge dimension, multiple locations"
    },
    {
      "label": "Bearing pad spacing",
      "value": "5'-0\"",
      "unit": "ft-in",
      "appliesTo": "Bearing marks (*) near beam ends, x2"
    },
    {
      "label": "Fillet thickness",
      "value": "8\"",
      "unit": "in",
      "appliesTo": "Fillet, typ."
    },
    {
      "label": "Diaphragm thickness",
      "value": "10\"",
      "unit": "in",
      "appliesTo": "Concrete diaphragm, typ."
    },
    {
      "label": "Paving rest width",
      "value": "12\"",
      "unit": "in",
      "appliesTo": "Paving rest"
    },
    {
      "label": "Endwall thickness",
      "value": "3'-0\"",
      "unit": "ft-in",
      "appliesTo": "Endwall outside exterior beam, typ."
    },
    {
      "label": "Endwall thickness",
      "value": "1'-6\"",
      "unit": "ft-in",
      "appliesTo": "Endwall"
    },
    {
      "label": "Edgebeam width",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "Edgebeam, typ."
    },
    {
      "label": "Gutter to gutter width",
      "value": "40'-0\"",
      "unit": "ft-in",
      "appliesTo": "Deck cross width"
    },
    {
      "label": "Out to out width",
      "value": "43'-7\"",
      "unit": "ft-in",
      "appliesTo": "Deck cross width"
    },
    {
      "label": "Overhang dimension",
      "value": "1'-9 1/2\"",
      "unit": "ft-in",
      "appliesTo": "Deck overhang, repeated top and bottom"
    },
    {
      "label": "Distance",
      "value": "22'-0\"",
      "unit": "ft-in",
      "appliesTo": "Between gutter lines, both bridges"
    },
    {
      "label": "Skew angle",
      "value": "81°-20'-05.0\"",
      "unit": "deg-min-sec",
      "appliesTo": "Beam/skew angle, typ., repeated multiple times"
    },
    {
      "label": "Bearing",
      "value": "N 83°-43'-21.7\" E",
      "unit": "",
      "appliesTo": "Construction bearing line"
    },
    {
      "label": "End post dimension",
      "value": "4'-3\"",
      "unit": "ft-in",
      "appliesTo": "End post, upper deck"
    },
    {
      "label": "End post dimension",
      "value": "4'-6\"",
      "unit": "ft-in",
      "appliesTo": "End post, lower deck"
    },
    {
      "label": "Diagonal dimension",
      "value": "17'-4 5/16\"",
      "unit": "ft-in",
      "appliesTo": "Skewed deck edge segment"
    },
    {
      "label": "Diagonal dimension",
      "value": "17'-5 1/4\"",
      "unit": "ft-in",
      "appliesTo": "Skewed deck edge segment, x2"
    },
    {
      "label": "Total diagonal dimension",
      "value": "52'-2 13/16\"",
      "unit": "ft-in",
      "appliesTo": "Skewed deck edge total, upper deck"
    },
    {
      "label": "Diagonal dimension",
      "value": "17'-2 13/16\"",
      "unit": "ft-in",
      "appliesTo": "Skewed deck edge segment, lower deck, x2"
    },
    {
      "label": "Diagonal dimension",
      "value": "17'-2 3/4\"",
      "unit": "ft-in",
      "appliesTo": "Skewed deck edge segment, lower deck"
    },
    {
      "label": "Total diagonal dimension",
      "value": "51'-8 3/8\"",
      "unit": "ft-in",
      "appliesTo": "Skewed deck edge total, lower deck"
    },
    {
      "label": "Fence post spacing",
      "value": "8'-9\"",
      "unit": "ft-in",
      "appliesTo": "Fence post spacing, repeated multiple times"
    },
    {
      "label": "Fence post spacing",
      "value": "8'-0\"",
      "unit": "ft-in",
      "appliesTo": "Fence post spacing, x2"
    },
    {
      "label": "Fence post spacing",
      "value": "6'-8 13/16\"",
      "unit": "ft-in",
      "appliesTo": "Fence post spacing, upper deck end"
    },
    {
      "label": "Fence post spacing",
      "value": "6'-2 3/8\"",
      "unit": "ft-in",
      "appliesTo": "Fence post spacing, lower deck end"
    }
  ],
  "notes": [],
  "labels": [
    "DECK PLAN",
    "SPAN 1",
    "CONSTRUCTION CL SR 21",
    "PGL WESTBOUND",
    "PGL EASTBOUND",
    "FENCE POST SPACING",
    "END POST",
    "B.F.P.R. BENT 1",
    "CL BEAM 1",
    "CL BEAM 2",
    "CL BEAM 3",
    "CL BEAM 4",
    "CL BEAM 5",
    "CL BEAM 6",
    "CL BEAM 7",
    "CL BEAM 8",
    "CL BEAM 9",
    "CL BEAM 10",
    "CL BEAM 11",
    "CL BEAM 12"
  ],
  "description": "This crop shows the Deck Plan for Span 1 of a twin-bridge structure, depicting the westbound and eastbound decks side by side with beam centerlines (Beams 1–12), endwalls, edgebeams, diaphragms, paving rests, and end posts. It is heavily dimensioned with panel widths, skew angles (81°-20'-05.0\"), fence post spacing, and gutter-to-gutter/out-to-out widths, and references reinforcing bar marks 12-502A/B/C and 400A along with a construction centerline (SR 21) and bearing call-out."
}

{
  "view": "Plan",
  "objects": [
    {
      "name": "Bridge deck (beam bay)",
      "tag": "",
      "shape": "trapezoidal/skewed rectangular",
      "material": "concrete deck slab",
      "count": 2,
      "note": "Two adjacent skewed deck plan panels shown, upper (westbound) and lower (eastbound), each 82'-0\" long with 12 beams total, 6 per panel"
    },
    {
      "name": "Beam",
      "tag": "BEAM 1",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": "Centerline of beam shown as dashed line, upper panel"
    },
    {
      "name": "Beam",
      "tag": "BEAM 2",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "Beam",
      "tag": "BEAM 3",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "Beam",
      "tag": "BEAM 4",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "Beam",
      "tag": "BEAM 5",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "Beam",
      "tag": "BEAM 6",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "Beam",
      "tag": "BEAM 7",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": "Lower panel, eastbound"
    },
    {
      "name": "Beam",
      "tag": "BEAM 8",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "Beam",
      "tag": "BEAM 9",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "Beam",
      "tag": "BEAM 10",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "Beam",
      "tag": "BEAM 11",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "Beam",
      "tag": "BEAM 12",
      "shape": "straight, parallel line",
      "material": "",
      "count": 1,
      "note": ""
    },
    {
      "name": "Concrete diaphragm",
      "tag": "",
      "shape": "transverse strip, rectangular in plan",
      "material": "concrete",
      "count": 2,
      "note": "Shown as \"10\" CONCRETE DIAPHRAGM, TYP.\" crossing beams in both deck panels"
    },
    {
      "name": "Edgebeam",
      "tag": "",
      "shape": "linear strip along deck edge",
      "material": "concrete (implied)",
      "count": 4,
      "note": "1'-0\" EDGEBEAM, TYP., along outer edges of both deck panels"
    },
    {
      "name": "Fillet",
      "tag": "",
      "shape": "linear strip",
      "material": "concrete (implied)",
      "count": 4,
      "note": "8\" FILLET, TYP., shown at beam-deck edge transitions"
    },
    {
      "name": "Reinforcement bar",
      "tag": "12-502D",
      "shape": "bent bar, hooked end shown in plan",
      "material": "reinforcing steel",
      "count": 8,
      "note": "Repeated transverse bars along both top and bottom deck edges of each panel"
    },
    {
      "name": "Reinforcement bar",
      "tag": "12-502E",
      "shape": "bent bar, hooked end shown in plan",
      "material": "reinforcing steel",
      "count": 4,
      "note": "End bar at edge of fence post spacing zone, both panels"
    },
    {
      "name": "Reinforcement bar",
      "tag": "400B",
      "shape": "straight longitudinal bar",
      "material": "reinforcing steel",
      "count": 2,
      "note": "Longitudinal bar shown within deck panel, one callout per panel"
    },
    {
      "name": "Reinforcement bar",
      "tag": "400C",
      "shape": "straight longitudinal bar with lap splice",
      "material": "reinforcing steel",
      "count": 2,
      "note": "Shown with 2'-0\" MIN. LAP callout, one per panel"
    },
    {
      "name": "Fence post spacing (fence line)",
      "tag": "",
      "shape": "linear spacing marks",
      "material": "",
      "count": null,
      "note": "Marked along both outer edges of both deck panels with 3'-0\"/9'-6\" spacing pattern"
    }
  ],
  "measurements": [
    {
      "label": "Overall deck length",
      "value": "82'-0\"",
      "unit": "ft-in",
      "appliesTo": "upper panel (westbound)"
    },
    {
      "label": "Overall deck length",
      "value": "82'-0\"",
      "unit": "ft-in",
      "appliesTo": "lower panel (eastbound)"
    },
    {
      "label": "Bay spacing",
      "value": "16'-4 1/2\"",
      "unit": "ft-in",
      "appliesTo": "upper and lower panels, repeated 4 times"
    },
    {
      "label": "End bay spacing",
      "value": "16'-6\"",
      "unit": "ft-in",
      "appliesTo": "end bay, both panels"
    },
    {
      "label": "Sub-spacing",
      "value": "9'-6\"",
      "unit": "ft-in",
      "appliesTo": "top and bottom edge dimension lines, both panels"
    },
    {
      "label": "Sub-spacing",
      "value": "9'-10 1/2\"",
      "unit": "ft-in",
      "appliesTo": "inner dimension lines near beams, both panels"
    },
    {
      "label": "Edge offset",
      "value": "3'-0\"",
      "unit": "ft-in",
      "appliesTo": "fence post spacing start/end, outer edges"
    },
    {
      "label": "Edge offset",
      "value": "2'-0\"",
      "unit": "ft-in",
      "appliesTo": "fence post spacing inner edge, both panels"
    },
    {
      "label": "Edge offset",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "fence post spacing inner edge, both panels"
    },
    {
      "label": "Fence post spacing gap",
      "value": "5'-0\"",
      "unit": "ft-in",
      "appliesTo": "paired spacing marks at both ends of upper and lower panels"
    },
    {
      "label": "Skew angle",
      "value": "81°-20'-05.0\"",
      "unit": "",
      "appliesTo": "construction centerline SR 21 / beam skew, typical"
    },
    {
      "label": "Bearing",
      "value": "N 83°-43'-21.7\" E",
      "unit": "",
      "appliesTo": "centerline reference between panels"
    },
    {
      "label": "Diaphragm thickness",
      "value": "10\"",
      "unit": "in",
      "appliesTo": "concrete diaphragm, typical"
    },
    {
      "label": "Fillet dimension",
      "value": "8\"",
      "unit": "in",
      "appliesTo": "fillet, typical"
    },
    {
      "label": "Edgebeam width",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "edgebeam, typical"
    },
    {
      "label": "Lap length",
      "value": "2'-0\"",
      "unit": "ft-in",
      "appliesTo": "400C bar minimum lap"
    },
    {
      "label": "Gutter to gutter width",
      "value": "40'-0\"",
      "unit": "ft-in",
      "appliesTo": "deck cross width, both panels"
    },
    {
      "label": "Out to out width",
      "value": "43'-7\"",
      "unit": "ft-in",
      "appliesTo": "deck cross width, both panels"
    },
    {
      "label": "Edge dimension",
      "value": "1'-9 1/2\"",
      "unit": "ft-in",
      "appliesTo": "outer edge to gutter line, both panels"
    },
    {
      "label": "Half-width dimension",
      "value": "22'-0\"",
      "unit": "ft-in",
      "appliesTo": "centerline to gutter, both panels"
    }
  ],
  "notes": [
    "8\" FILLET, TYP.",
    "1'-0\" EDGEBEAM, TYP.",
    "10\" CONCRETE DIAPHRAGM, TYP.",
    "2'-0\" MIN. LAP",
    "81°-20'-05.0\", TYP.",
    "FENCE POST SPACING"
  ],
  "labels": [
    "SPAN 2",
    "PGL WESTBOUND",
    "PGL EASTBOUND",
    "CONSTRUCTION ℄ SR 21"
  ],
  "description": "This crop is a plan view of Span 2 of a bridge deck, showing two adjacent skewed deck panels (westbound and eastbound roadways) each 82'-0\" long and containing six precast beams (Beams 1-6 upper, 7-12 lower). It details deck reinforcement bar marks (12-502D, 12-502E, 400B, 400C), edgebeam and fillet callouts, concrete diaphragm locations, fence post spacing along the deck edges, and overall/partial transverse dimensions (gutter-to-gutter, out-to-out) along with the roadway skew angle and centerline bearing."
}

{
  "view": "Plan",
  "objects": [
    {
      "name": "beam",
      "tag": "BEAM 1 through BEAM 12",
      "shape": "straight, skewed at ends",
      "material": "",
      "count": 12,
      "note": "centerlines shown for each beam, in two groups of six (westbound and eastbound decks)"
    },
    {
      "name": "deck slab",
      "tag": "",
      "shape": "trapezoidal/skewed rectangular",
      "material": "concrete",
      "count": 2,
      "note": "one deck panel per roadway (PGL Westbound and PGL Eastbound), each spanning between skewed end lines"
    },
    {
      "name": "concrete diaphragm",
      "tag": "",
      "shape": "transverse strip",
      "material": "concrete",
      "count": null,
      "note": "labeled '10\" CONCRETE DIAPHRAGM, TYP.' at multiple locations between beams"
    },
    {
      "name": "edge beam",
      "tag": "",
      "shape": "linear strip along deck edge",
      "material": "concrete",
      "count": 4,
      "note": "labeled '1'-0\" EDGEBEAM, TYP.' along outer edges of both decks"
    },
    {
      "name": "fillet",
      "tag": "",
      "shape": "linear strip",
      "material": "concrete",
      "count": 4,
      "note": "labeled '8\" FILLET, TYP.' along beam edges"
    },
    {
      "name": "reinforcement bar",
      "tag": "502D",
      "shape": "bar, bent detail shown",
      "material": "reinforcement steel",
      "count": 8,
      "note": "top transverse bars along deck edges, spaced between beam groups"
    },
    {
      "name": "reinforcement bar",
      "tag": "502E",
      "shape": "bar",
      "material": "reinforcement steel",
      "count": 4,
      "note": "end bars at outer edges of deck, near fence post spacing zones"
    },
    {
      "name": "reinforcement bar",
      "tag": "400B",
      "shape": "bar, longitudinal",
      "material": "reinforcement steel",
      "count": 2,
      "note": "longitudinal bar labeled '400B' within deck reinforcement layers"
    },
    {
      "name": "reinforcement bar",
      "tag": "400C",
      "shape": "bar, longitudinal",
      "material": "reinforcement steel",
      "count": 2,
      "note": "longitudinal bar labeled '400C', shown near '2'-0\" MIN. LAP' callout"
    },
    {
      "name": "fence post",
      "tag": "",
      "shape": "",
      "material": "",
      "count": null,
      "note": "only spacing dimensions shown, posts themselves not drawn; labeled 'FENCE POST SPACING'"
    }
  ],
  "measurements": [
    {
      "label": "overall deck width",
      "value": "82'-0\"",
      "unit": "",
      "appliesTo": "deck (both spans/decks)"
    },
    {
      "label": "panel spacing",
      "value": "16'-4 1/2\"",
      "unit": "",
      "appliesTo": "deck transverse spacing, repeated 4 times"
    },
    {
      "label": "end panel spacing",
      "value": "16'-6\"",
      "unit": "",
      "appliesTo": "deck transverse spacing, end panel"
    },
    {
      "label": "sub-spacing",
      "value": "9'-6\"",
      "unit": "",
      "appliesTo": "spacing between 502D/502E bars, top row"
    },
    {
      "label": "sub-spacing (alt row)",
      "value": "9'-10 1/2\"",
      "unit": "",
      "appliesTo": "spacing between 502D/502E bars, second row"
    },
    {
      "label": "end offset",
      "value": "3'-0\"",
      "unit": "",
      "appliesTo": "edge offset to first bar/fence post, top and bottom rows"
    },
    {
      "label": "end offset (alt)",
      "value": "2'-0\"",
      "unit": "",
      "appliesTo": "edge offset to first bar, middle rows"
    },
    {
      "label": "end offset (alt)",
      "value": "1'-0\"",
      "unit": "",
      "appliesTo": "edge offset near fence post spacing, middle rows"
    },
    {
      "label": "fillet thickness",
      "value": "8\"",
      "unit": "in",
      "appliesTo": "fillet, typ."
    },
    {
      "label": "edgebeam width",
      "value": "1'-0\"",
      "unit": "",
      "appliesTo": "edgebeam, typ."
    },
    {
      "label": "diaphragm thickness",
      "value": "10\"",
      "unit": "in",
      "appliesTo": "concrete diaphragm, typ."
    },
    {
      "label": "minimum lap",
      "value": "2'-0\"",
      "unit": "",
      "appliesTo": "400B/400C bar lap, marked with ** symbol"
    },
    {
      "label": "skew angle",
      "value": "81°-20'-05.0\"",
      "unit": "",
      "appliesTo": "deck end skew, typ."
    },
    {
      "label": "bearing",
      "value": "N 83°-43'-21.7\" E",
      "unit": "",
      "appliesTo": "construction centerline SR 21"
    },
    {
      "label": "gutter to gutter width",
      "value": "40'-0\"",
      "unit": "",
      "appliesTo": "westbound and eastbound deck"
    },
    {
      "label": "out to out width",
      "value": "43'-7\"",
      "unit": "",
      "appliesTo": "westbound and eastbound deck"
    },
    {
      "label": "curb offset",
      "value": "1'-9 1/2\"",
      "unit": "",
      "appliesTo": "gutter to out-to-out edge offset"
    },
    {
      "label": "lap bar spacing at ends",
      "value": "5'-0\"",
      "unit": "",
      "appliesTo": "** marked lap bars near deck ends"
    },
    {
      "label": "median width",
      "value": "22'-0\"",
      "unit": "",
      "appliesTo": "distance between PGL Westbound and PGL Eastbound centerlines"
    },
    {
      "label": "span label",
      "value": "SPAN 2",
      "unit": "",
      "appliesTo": "overall deck plan"
    }
  ],
  "notes": [],
  "labels": [
    "SPAN 2",
    "CONSTRUCTION ℄ SR 21",
    "PGL WESTBOUND",
    "PGL EASTBOUND",
    "FENCE POST SPACING",
    "8\" FILLET, TYP.",
    "1'-0\" EDGEBEAM, TYP.",
    "10\" CONCRETE DIAPHRAGM, TYP.",
    "2'-0\" MIN. LAP",
    "℄ BEAM 1",
    "℄ BEAM 2",
    "℄ BEAM 3",
    "℄ BEAM 4",
    "℄ BEAM 5",
    "℄ BEAM 6",
    "℄ BEAM 7",
    "℄ BEAM 8",
    "℄ BEAM 9",
    "℄ BEAM 10",
    "℄ BEAM 11",
    "℄ BEAM 12"
  ],
  "description": "This crop is a plan view of Span 2 of a twin-roadway bridge deck, showing two parallel skewed deck panels (westbound and eastbound) each supported on six beams (Beams 1-6 and 7-12), with dimensioned transverse spacing, edge beams, fillets, concrete diaphragms, and top-slab reinforcement bars (502D, 502E, 400B, 400C) including a minimum lap callout. Overall deck geometry (82'-0\" width, 81°20'05.0\" skew, gutter-to-gutter and out-to-out widths) and the SR 21 construction centerline bearing are also annotated."
}

{
  "view": "Notes",
  "objects": [
    {
      "name": "reinforcement bar",
      "tag": "600",
      "shape": "",
      "material": "reinforced concrete (rebar)",
      "count": null,
      "note": "referenced as 2-600 bars, 10'-0\" long, placed between pairs of 400 bars"
    },
    {
      "name": "reinforcement bar",
      "tag": "400",
      "shape": "",
      "material": "reinforced concrete (rebar)",
      "count": null,
      "note": "bars in top of slab over intermediate bents 2 and 3"
    },
    {
      "name": "deck slab",
      "tag": "",
      "shape": "",
      "material": "reinforced concrete",
      "count": null,
      "note": "slab over intermediate bents referenced in note 5"
    },
    {
      "name": "bent",
      "tag": "Bent 2",
      "shape": "",
      "material": "",
      "count": 1,
      "note": "intermediate bent referenced in note text"
    },
    {
      "name": "bent",
      "tag": "Bent 3",
      "shape": "",
      "material": "",
      "count": 1,
      "note": "intermediate bent referenced in note text"
    }
  ],
  "measurements": [
    {
      "label": "length",
      "value": "10'-0\"",
      "unit": "",
      "appliesTo": "600 bar"
    },
    {
      "label": "quantity",
      "value": "2",
      "unit": "",
      "appliesTo": "600 bar, per pair of 400 bars"
    }
  ],
  "notes": [
    "...CONSTRUCTION JOINT IN DECK.",
    "5. 2-600 (10'-0\" LONG) BETWEEN EACH PAIR OF 400 BARS IN TOP OF SLAB OVER INTERMEDIATE BENTS 2 AND 3.",
    "6. LAP IN BARS SHALL BE STAGGERED AND ALTERNATED TO MAXIMIZE THE DISTANCE BETWEEN ADJACENT SPLICES."
  ],
  "labels": [],
  "description": "This crop shows a partial list of general construction notes, specifically items 5 and 6 (with a fragment of a note above referencing a construction joint in deck), concerning placement and staggering of reinforcement bars (600 and 400 bar marks) in the top of the deck slab over intermediate bents 2 and 3. It is a text-only notes block, not a plan or detail view, and appears to be part of a larger reinforcement notes list on the sheet."
}

{
  "view": "Cross Section",
  "objects": [
    {
      "name": "Deck slab",
      "tag": "",
      "shape": "flat with 2% cross slope",
      "material": "reinforced concrete",
      "count": 1,
      "note": "7 3/4\" thick between beams, 8\" in overhangs; top slab of bridge cross section"
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 1",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": "exterior beam, left side"
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 2",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": "interior beam"
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 3",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": "interior beam"
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 4",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": "interior beam"
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 5",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": "interior beam"
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 6",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": "exterior beam, right side"
    },
    {
      "name": "Diaphragm",
      "tag": "",
      "shape": "rectangular, cast between beams",
      "material": "reinforced concrete",
      "count": 5,
      "note": "shown in lower 'SECTION THRU DIAPHRAGM' view, between each pair of adjacent beams"
    },
    {
      "name": "Reinforcement bar",
      "tag": "400A",
      "shape": "bar (deck top mat)",
      "material": "reinforcement steel",
      "count": null,
      "note": "spaced as shown, groups of 6, 14, 30 at various locations along slab"
    },
    {
      "name": "Reinforcement bar",
      "tag": "500A",
      "shape": "bar (deck bottom mat)",
      "material": "reinforcement steel",
      "count": null,
      "note": "at 6 1/2\" spacing"
    },
    {
      "name": "Reinforcement bar",
      "tag": "501",
      "shape": "bar",
      "material": "reinforcement steel",
      "count": null,
      "note": "placed under every 500A bar"
    },
    {
      "name": "Reinforcement bar",
      "tag": "502",
      "shape": "bar",
      "material": "reinforcement steel",
      "count": null,
      "note": "placed at every 500A bar"
    },
    {
      "name": "Reinforcement bar",
      "tag": "403A",
      "shape": "bar (diaphragm)",
      "material": "reinforcement steel",
      "count": 7,
      "note": "at equal spaces, in diaphragm section"
    },
    {
      "name": "Reinforcement bar",
      "tag": "402A",
      "shape": "bar (diaphragm)",
      "material": "reinforcement steel",
      "count": 4,
      "note": "diaphragm reinforcement"
    },
    {
      "name": "Reinforcement bar",
      "tag": "507A",
      "shape": "bar (diaphragm)",
      "material": "reinforcement steel",
      "count": 2,
      "note": "diaphragm reinforcement, shown twice at two locations"
    },
    {
      "name": "Plain bar (tie rod)",
      "tag": "",
      "shape": "circular, 1\" diameter",
      "material": "plain steel",
      "count": null,
      "note": "through diaphragms"
    },
    {
      "name": "Drip bead",
      "tag": "",
      "shape": "triangular",
      "material": "unspecified (likely sealant/concrete)",
      "count": 1,
      "note": "3/4\" triangular drip bead, full length of bridge, typical at fascia edge"
    },
    {
      "name": "Construction joint",
      "tag": "",
      "shape": "linear, parallel to deck",
      "material": "",
      "count": 1,
      "note": "required construction joint parallel with deck, typ."
    },
    {
      "name": "Fence (not shown)",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 0,
      "note": "noted as not shown but location indicated typ. at both edges"
    }
  ],
  "measurements": [
    {
      "label": "Out to out width",
      "value": "43'-7\"",
      "unit": "",
      "appliesTo": "deck cross section"
    },
    {
      "label": "Gutter to gutter width",
      "value": "40'-0\"",
      "unit": "",
      "appliesTo": "deck cross section"
    },
    {
      "label": "Width dimension",
      "value": "34'-0\"",
      "unit": "",
      "appliesTo": "deck cross section"
    },
    {
      "label": "Right side offset",
      "value": "22'-0\"",
      "unit": "",
      "appliesTo": "deck cross section, from centerline"
    },
    {
      "label": "Right side offset",
      "value": "14'-2 1/2\"",
      "unit": "",
      "appliesTo": "deck cross section, from edge"
    },
    {
      "label": "Right shoulder/lane width",
      "value": "6'-0\"",
      "unit": "",
      "appliesTo": "deck cross section, right of PGL"
    },
    {
      "label": "Overhang width",
      "value": "1'-8\"",
      "unit": "",
      "appliesTo": "left and right overhangs"
    },
    {
      "label": "Edge offset",
      "value": "1 1/2\"",
      "unit": "",
      "appliesTo": "outer edge dimension, both sides"
    },
    {
      "label": "Edge thickness",
      "value": "8\"",
      "unit": "",
      "appliesTo": "overhang slab thickness, both sides"
    },
    {
      "label": "Slab thickness between beams",
      "value": "7 3/4\"",
      "unit": "",
      "appliesTo": "slab"
    },
    {
      "label": "Cross slope",
      "value": "2%",
      "unit": "%",
      "appliesTo": "deck slab"
    },
    {
      "label": "Clear cover top",
      "value": "2 1/4\"",
      "unit": "",
      "appliesTo": "deck reinforcement"
    },
    {
      "label": "Clear cover bottom",
      "value": "1\"",
      "unit": "",
      "appliesTo": "deck reinforcement"
    },
    {
      "label": "Dimension D interior beams",
      "value": "8 3/4\"",
      "unit": "",
      "appliesTo": "interior beams"
    },
    {
      "label": "Dimension D exterior beams",
      "value": "9 1/8\"",
      "unit": "",
      "appliesTo": "exterior beams"
    },
    {
      "label": "Rebar spacing 500A",
      "value": "6 1/2\"",
      "unit": "",
      "appliesTo": "500A bars"
    },
    {
      "label": "Rebar group",
      "value": "30-400A",
      "unit": "",
      "appliesTo": "400A bars, spaced as shown"
    },
    {
      "label": "Rebar group",
      "value": "6-400A",
      "unit": "",
      "appliesTo": "400A bars at eq. sps., both sides"
    },
    {
      "label": "Rebar group",
      "value": "14-400A",
      "unit": "",
      "appliesTo": "400A bars at equal spaces, typ., near center"
    },
    {
      "label": "Bearing offset dimension",
      "value": "4 3/8\"",
      "unit": "",
      "appliesTo": "both edges of section"
    },
    {
      "label": "Offset dimension",
      "value": "3\"",
      "unit": "",
      "appliesTo": "multiple locations along section, typ."
    },
    {
      "label": "Minimum offset",
      "value": "3'-0\" MIN.",
      "unit": "",
      "appliesTo": "typ. dimension near right side"
    },
    {
      "label": "Beam spacing",
      "value": "3'-0 1/2\"",
      "unit": "",
      "appliesTo": "Beam 1 and Beam 6 to edge"
    },
    {
      "label": "Beam spacing",
      "value": "7'-6\"",
      "unit": "",
      "appliesTo": "spacing between Beam 1-2, 2-3, 3-4, 4-5, 5-6"
    },
    {
      "label": "Rebar group diaphragm",
      "value": "7-403A",
      "unit": "",
      "appliesTo": "403A bars at equal spaces, diaphragm section"
    },
    {
      "label": "Diaphragm edge offset",
      "value": "5\"",
      "unit": "",
      "appliesTo": "diaphragm section, both sides"
    },
    {
      "label": "Plain bar diameter",
      "value": "1\"",
      "unit": "",
      "appliesTo": "plain tie bar, diaphragm"
    }
  ],
  "notes": [
    "DIMENSION \"D\" IS MEASURED FROM TOP OF SLAB TO TOP OF BEAMS AT CENTERLINE BEARING. VARY \"D\" BETWEEN BEARINGS TO COMPENSATE FOR DEAD LOAD DEFLECTION, AND VERTICAL CURVE.",
    "MAINTAIN A CONSTANT SLAB THICKNESS OF 7 3/4\" BETWEEN BEAMS AND 8\" IN THE OVERHANGS.",
    "\"D\" = 8 3/4\" INTERIOR BEAMS",
    "\"D\" = 9 1/8\" EXTERIOR BEAMS",
    "FENCE NOT SHOWN, TYP.",
    "502 AT EVERY 500A, TYP.",
    "30-400A SPACED AS SHOWN",
    "500A AT 6 1/2\"",
    "501 UNDER EVERY 500A",
    "REQUIRED CONSTRUCTION JOINT PARALLEL WITH DECK, TYP.",
    "3/4\" TRIANGULAR DRIP BEAD FULL LENGTH OF BRIDGE, TYP.",
    "6-400A AT EQ. SPS.",
    "14-400A AT EQUAL SPACES, TYP.",
    "7-403A AT EQUAL SPACES",
    "1\" DIAMETER PLAIN BAR"
  ],
  "labels": [
    "SR 21 WB = PGL",
    "SECTION THRU SLAB",
    "SECTION THRU DIAPHRAGM",
    "C BEAM 1",
    "C BEAM 2",
    "C BEAM 3",
    "C BEAM 4",
    "C BEAM 5",
    "C BEAM 6"
  ],
  "description": "This crop shows two cross sections of a precast girder bridge superstructure: an upper 'SECTION THRU SLAB' spanning six beams (Beam 1 through Beam 6) with full deck slab dimensions, cross-slope, reinforcement (400A, 500A, 501, 502 bars), overhang and edge details, and a lower 'SECTION THRU DIAPHRAGM' showing diaphragm reinforcement (403A, 402A, 507A bars) and a plain tie bar between the same beam line. Notes at the top explain the variable dimension 'D' used to set beam elevations relative to the slab for dead load deflection and vertical curve compensation. This documents deck slab and diaphragm concrete/reinforcement quantities for a multi-beam concrete bridge deck."
}

{
  "view": "Elevation",
  "objects": [
    {
      "name": "Deck slab",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Shown in longitudinal elevation with reinforcement bars depicted as circles/dots along its length"
    },
    {
      "name": "Abutment/backwall",
      "tag": "",
      "shape": "tapered",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Sloped element at left end of deck"
    },
    {
      "name": "Intermediate bent (pier)",
      "tag": "",
      "shape": "tapered/hammerhead",
      "material": "reinforced concrete",
      "count": 2,
      "note": "Two similar pier shapes with flared tops supporting the slab"
    },
    {
      "name": "Reinforcement bar",
      "tag": "58-600",
      "shape": "circular (bar cross-section, shown as small circles)",
      "material": "reinforced concrete",
      "count": null,
      "note": "Placed 2 between each pair of 400 bars in top of slab over intermediate bents, per callout"
    },
    {
      "name": "Reinforcement bar",
      "tag": "400",
      "shape": "circular (bar cross-section, shown as dots)",
      "material": "reinforced concrete",
      "count": null,
      "note": "Bars in top of slab referenced by the 58-600 callout"
    }
  ],
  "measurements": [
    {
      "label": "58-600",
      "value": "58-600",
      "unit": "",
      "appliesTo": "Reinforcement bar spacing/count callout"
    }
  ],
  "notes": [
    "58-600 (2 BETWEEN EACH PAIR OF 400 BARS IN TOP OF SLAB OVER INTERMEDIATE BENTS)"
  ],
  "labels": [],
  "description": "This crop is a partial longitudinal elevation of a bridge superstructure showing a continuous deck slab spanning over an abutment (left, tapered) and two intermediate bents with flared/hammerhead tops. A leader note calls out reinforcement bar placement ('58-600') indicating two bars placed between each pair of 400 bars in the top of the slab over the intermediate bents. The drawing documents deck slab reinforcement detailing at pier locations."
}

{
  "view": "Cross Section",
  "objects": [
    {
      "name": "Girder/Beam",
      "tag": "I-509",
      "shape": "tapered/I-section (bulb-tee-like)",
      "material": "precast concrete",
      "count": 1,
      "note": "labeled with leader arrow to one of the deck beams"
    },
    {
      "name": "Girder/Beam",
      "tag": "I-508",
      "shape": "tapered/I-section (bulb-tee-like)",
      "material": "precast concrete",
      "count": 1,
      "note": "labeled with leader arrow to one of the deck beams"
    },
    {
      "name": "Girder/Beam",
      "tag": "I-802",
      "shape": "tapered/I-section (bulb-tee-like)",
      "material": "precast concrete",
      "count": 1,
      "note": "labeled with leader arrow near a support stem"
    },
    {
      "name": "Girder/Beam",
      "tag": "I-801",
      "shape": "tapered/I-section (bulb-tee-like)",
      "material": "precast concrete",
      "count": 1,
      "note": "labeled with leader arrow near a support stem"
    },
    {
      "name": "Edge Beam",
      "tag": "2-800",
      "shape": "rectangular with sloped top",
      "material": "reinforced concrete",
      "count": 1,
      "note": "outer edge beam at right side of deck, poured flush with outside face of beam"
    },
    {
      "name": "Deck Slab",
      "tag": "",
      "shape": "flat with cross slope",
      "material": "reinforced concrete",
      "count": 1,
      "note": "top slab spanning across all beams, shown with 2% slope arrow"
    },
    {
      "name": "Support Stem/Web (beam bottom flange support)",
      "tag": "",
      "shape": "trapezoidal/tapered stem",
      "material": "precast concrete",
      "count": 6,
      "note": "repeating tapered support stems beneath deck, spaced at '8-404 AT EQUAL SPACES'"
    },
    {
      "name": "Parapet/Barrier",
      "tag": "",
      "shape": "tapered vertical wall",
      "material": "reinforced concrete",
      "count": 2,
      "note": "one at each end of the section (left and right), with fence noted above right one"
    },
    {
      "name": "Fence",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 1,
      "note": "noted as 'FENCE NOT SHOWN, TYP.' atop right parapet, not drawn"
    },
    {
      "name": "Bearing Pad",
      "tag": "",
      "shape": "",
      "material": "",
      "count": null,
      "note": "noted as 'BEARING PADS NOT SHOWN' at bottom of section"
    }
  ],
  "measurements": [
    {
      "label": "Deck thickness",
      "value": "8",
      "unit": "in",
      "appliesTo": "deck slab, left edge, noted '8\", TYP.'"
    },
    {
      "label": "Beam spacing offset",
      "value": "2",
      "unit": "in",
      "appliesTo": "spacing dimension left of equal spaces group"
    },
    {
      "label": "Beam spacing offset",
      "value": "2",
      "unit": "in",
      "appliesTo": "spacing dimension right of equal spaces group"
    },
    {
      "label": "Equal spacing dimension",
      "value": "8-404",
      "unit": "",
      "appliesTo": "spacing group labeled 'AT EQUAL SPACES', likely 8 spaces at 404 (units unspecified, possibly mm or a mark)"
    },
    {
      "label": "Cross slope",
      "value": "2",
      "unit": "%",
      "appliesTo": "deck slab, direction arrow shown"
    }
  ],
  "notes": [
    "8-404 AT EQUAL SPACES",
    "FENCE NOT SHOWN, TYP.",
    "POUR EDGE BEAM FLUSH WITH OUTSIDE FACE OF BEAM, TYP.",
    "NOTE: BEARING PADS NOT SHOWN"
  ],
  "labels": [
    "SR 21 WB = PGL",
    "I-509",
    "I-508",
    "I-802",
    "I-801",
    "2-800",
    "8\", TYP."
  ],
  "description": "This crop is a cross section through a bridge superstructure showing a series of precast concrete beams (tagged I-509, I-508, I-801, I-802) supporting a concrete deck slab with a 2% cross slope, bounded by parapets/barriers at each edge. An edge beam (2-800) is shown at the right side poured flush with the outside face of the beam, and the profile grade line for SR 21 WB is marked near the right parapet. Notes indicate that bearing pads and the fence atop the right parapet are not shown in this view."
}

{
  "view": "Cross Section",
  "objects": [
    {
      "name": "Deck slab",
      "tag": "",
      "shape": "rectangular/tapered (crowned)",
      "material": "reinforced concrete",
      "count": 1,
      "note": "7.75\" thick between beams, 8\" in overhangs, 2% cross slope"
    },
    {
      "name": "PSC Beam",
      "tag": "BEAM 1",
      "shape": "bulb-tee/I-section",
      "material": "precast concrete",
      "count": 1,
      "note": "exterior beam"
    },
    {
      "name": "PSC Beam",
      "tag": "BEAM 2",
      "shape": "bulb-tee/I-section",
      "material": "precast concrete",
      "count": 1,
      "note": "interior beam"
    },
    {
      "name": "PSC Beam",
      "tag": "BEAM 3",
      "shape": "bulb-tee/I-section",
      "material": "precast concrete",
      "count": 1,
      "note": "interior beam"
    },
    {
      "name": "PSC Beam",
      "tag": "BEAM 4",
      "shape": "bulb-tee/I-section",
      "material": "precast concrete",
      "count": 1,
      "note": "interior beam"
    },
    {
      "name": "PSC Beam",
      "tag": "BEAM 5",
      "shape": "bulb-tee/I-section",
      "material": "precast concrete",
      "count": 1,
      "note": "interior beam"
    },
    {
      "name": "PSC Beam",
      "tag": "BEAM 6",
      "shape": "bulb-tee/I-section",
      "material": "precast concrete",
      "count": 1,
      "note": "exterior beam"
    },
    {
      "name": "Diaphragm",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 5,
      "note": "intermediate diaphragms between beams, shown in second section view"
    },
    {
      "name": "Edge parapet/barrier upstand",
      "tag": "",
      "shape": "tapered",
      "material": "reinforced concrete",
      "count": 2,
      "note": "fence-mounting curb at each edge, fence itself not shown"
    },
    {
      "name": "Reinforcement bar",
      "tag": "400A",
      "shape": "",
      "material": "steel",
      "count": null,
      "note": "transverse slab bars, spaced as noted (30-400A shown, also 6-400A, 14-400A groupings)"
    },
    {
      "name": "Reinforcement bar",
      "tag": "500A",
      "shape": "",
      "material": "steel",
      "count": null,
      "note": "longitudinal top bar at 6.5\" spacing"
    },
    {
      "name": "Reinforcement bar",
      "tag": "501",
      "shape": "",
      "material": "steel",
      "count": null,
      "note": "placed under every 500A"
    },
    {
      "name": "Reinforcement bar",
      "tag": "502",
      "shape": "",
      "material": "steel",
      "count": null,
      "note": "placed at every 500A"
    },
    {
      "name": "Reinforcement bar",
      "tag": "403A",
      "shape": "",
      "material": "steel",
      "count": 7,
      "note": "diaphragm bars, at equal spaces"
    },
    {
      "name": "Reinforcement bar",
      "tag": "402A",
      "shape": "",
      "material": "steel",
      "count": 4,
      "note": "diaphragm bars"
    },
    {
      "name": "Reinforcement bar",
      "tag": "507A",
      "shape": "",
      "material": "steel",
      "count": 2,
      "note": "diaphragm top bars"
    },
    {
      "name": "Reinforcement bar",
      "tag": "",
      "shape": "circular, plain",
      "material": "steel",
      "count": null,
      "note": "1\" diameter plain bar, likely a diaphragm through-rod"
    },
    {
      "name": "Construction joint",
      "tag": "",
      "shape": "linear",
      "material": "",
      "count": 1,
      "note": "required construction joint parallel with deck"
    },
    {
      "name": "Drip bead",
      "tag": "",
      "shape": "triangular",
      "material": "",
      "count": 2,
      "note": "3/4\" triangular drip bead, full length of bridge, typical at each fascia edge"
    }
  ],
  "measurements": [
    {
      "label": "Slab thickness between beams",
      "value": "7 3/4",
      "unit": "in",
      "appliesTo": "deck slab"
    },
    {
      "label": "Slab thickness in overhangs",
      "value": "8",
      "unit": "in",
      "appliesTo": "deck slab overhang"
    },
    {
      "label": "Dimension D, interior beams",
      "value": "8 3/4",
      "unit": "in",
      "appliesTo": "interior beams"
    },
    {
      "label": "Dimension D, exterior beams",
      "value": "9 1/8",
      "unit": "in",
      "appliesTo": "exterior beams"
    },
    {
      "label": "Overall width",
      "value": "22'-0\"",
      "unit": "",
      "appliesTo": "half-width dimension shown at top right"
    },
    {
      "label": "Out to out width",
      "value": "43'-7\"",
      "unit": "",
      "appliesTo": "deck"
    },
    {
      "label": "Right side width",
      "value": "14'-2 1/2\"",
      "unit": "",
      "appliesTo": "deck"
    },
    {
      "label": "Gutter to gutter",
      "value": "40'-0\"",
      "unit": "",
      "appliesTo": "deck"
    },
    {
      "label": "Width dimension",
      "value": "34'-0\"",
      "unit": "",
      "appliesTo": "deck (between beam 1 and beam 6 approx)"
    },
    {
      "label": "Right lane dimension",
      "value": "6'-0\"",
      "unit": "",
      "appliesTo": "deck"
    },
    {
      "label": "Overhang edge width",
      "value": "1'-8\"",
      "unit": "",
      "appliesTo": "edge overhang, both sides"
    },
    {
      "label": "Edge offset",
      "value": "1 1/2\"",
      "unit": "in",
      "appliesTo": "edge, both sides"
    },
    {
      "label": "Minimum shoulder/lane width",
      "value": "3'-0\"",
      "unit": "",
      "appliesTo": "MIN. TYP. dimension"
    },
    {
      "label": "Edge thickness",
      "value": "8\"",
      "unit": "in",
      "appliesTo": "left edge curb"
    },
    {
      "label": "Edge thickness",
      "value": "3\"",
      "unit": "in",
      "appliesTo": "right edge curb"
    },
    {
      "label": "Beam spacing",
      "value": "7'-6\"",
      "unit": "",
      "appliesTo": "beam 1-2, 2-3, 3-4, 4-5, 5-6 spacing, each"
    },
    {
      "label": "End overhang beam to edge",
      "value": "3'-0 1/2\"",
      "unit": "",
      "appliesTo": "left and right end overhangs"
    },
    {
      "label": "500A spacing",
      "value": "6 1/2",
      "unit": "in",
      "appliesTo": "500A bars"
    },
    {
      "label": "502 spacing",
      "value": "",
      "unit": "",
      "appliesTo": "502 bars, at every 500A"
    },
    {
      "label": "30-400A spacing note",
      "value": "30",
      "unit": "count",
      "appliesTo": "400A bars, spaced as shown"
    },
    {
      "label": "6-400A at equal spaces",
      "value": "6",
      "unit": "count",
      "appliesTo": "400A bars near edges"
    },
    {
      "label": "14-400A at equal spaces",
      "value": "14",
      "unit": "count",
      "appliesTo": "400A bars mid-span"
    },
    {
      "label": "Clear cover top",
      "value": "2 1/4\"",
      "unit": "in",
      "appliesTo": "top clear cover, CL."
    },
    {
      "label": "Clear cover bottom",
      "value": "1\"",
      "unit": "in",
      "appliesTo": "bottom clear cover, CL."
    },
    {
      "label": "Side clear spacing typ",
      "value": "3\"",
      "unit": "in",
      "appliesTo": "typical spacing between bar groups"
    },
    {
      "label": "Edge vertical dimension",
      "value": "4 3/8\"",
      "unit": "in",
      "appliesTo": "left and right edge vertical dim"
    },
    {
      "label": "Drip bead size",
      "value": "3/4\"",
      "unit": "in",
      "appliesTo": "triangular drip bead"
    },
    {
      "label": "Diaphragm bar spacing offset",
      "value": "5\"",
      "unit": "in",
      "appliesTo": "403A bar group offset, both sides"
    },
    {
      "label": "403A bar count",
      "value": "7",
      "unit": "count",
      "appliesTo": "403A bars at equal spaces"
    },
    {
      "label": "402A bar count",
      "value": "4",
      "unit": "count",
      "appliesTo": "402A bars"
    },
    {
      "label": "507A bar count",
      "value": "2",
      "unit": "count",
      "appliesTo": "507A bars"
    },
    {
      "label": "Plain bar diameter",
      "value": "1\"",
      "unit": "in",
      "appliesTo": "plain bar in diaphragm"
    },
    {
      "label": "Cross slope",
      "value": "2",
      "unit": "%",
      "appliesTo": "deck slab, both sections"
    }
  ],
  "notes": [
    "DIMENSION \"D\" IS MEASURED FROM TOP OF SLAB TO TOP OF BEAMS AT CENTERLINE BEARING. VARY \"D\" BETWEEN BEARINGS TO COMPENSATE FOR DEAD LOAD DEFLECTION, AND VERTICAL CURVE.",
    "MAINTAIN A CONSTANT SLAB THICKNESS OF 7 3/4\" BETWEEN BEAMS AND 8\" IN THE OVERHANGS.",
    "\"D\" = 8 3/4\" INTERIOR BEAMS",
    "\"D\" = 9 1/8\" EXTERIOR BEAMS",
    "FENCE NOT SHOWN, TYP.",
    "REQUIRED CONSTRUCTION JOINT PARALLEL WITH DECK, TYP.",
    "3/4\" TRIANGULAR DRIP BEAD FULL LENGTH OF BRIDGE, TYP."
  ],
  "labels": [
    "SECTION THRU SLAB",
    "SECTION THRU DIAPHRAGM",
    "SR 21 WB = PGL",
    "C BEAM 1",
    "C BEAM 2",
    "C BEAM 3",
    "C BEAM 4",
    "C BEAM 5",
    "C BEAM 6"
  ],
  "description": "This crop contains two bridge deck cross sections: a 'SECTION THRU SLAB' showing six precast beams supporting a cast-in-place concrete deck slab with cross slope, overhangs, edge curbs, and detailed reinforcement (400A, 500A, 501, 502) with clear cover callouts and beam spacing dimensions; and a 'SECTION THRU DIAPHRAGM' below it showing intermediate diaphragms between the same six beams with reinforcement (403A, 402A, 507A) and a 1\" diameter plain bar. Together these document the deck slab thickness, camber/build-up dimension \"D\" for interior/exterior beams, overall deck geometry, and diaphragm reinforcement layout for this bridge span."
}

{
  "view": "Elevation",
  "objects": [
    {
      "name": "deck slab",
      "tag": "",
      "shape": "rectangular, elongated",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Shown in longitudinal elevation with reinforcement dots along top and bottom faces"
    },
    {
      "name": "bent",
      "tag": "",
      "shape": "tapered column with flared cap, I-shaped/hourglass profile",
      "material": "reinforced concrete",
      "count": 2,
      "note": "Intermediate bents supporting the slab"
    },
    {
      "name": "abutment/end support",
      "tag": "",
      "shape": "trapezoidal, tapered",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Shown at left end of slab, partially cropped"
    },
    {
      "name": "reinforcement bar",
      "tag": "400",
      "shape": "straight bar, paired",
      "material": "reinforced concrete reinforcement",
      "count": null,
      "note": "Bars in top of slab over intermediate bents, referenced by callout"
    },
    {
      "name": "reinforcement bar",
      "tag": "58-600",
      "shape": "straight bar",
      "material": "reinforced concrete reinforcement",
      "count": 58,
      "note": "Callout indicates 58 bars at 600 spacing, 2 placed between each pair of 400 bars"
    }
  ],
  "measurements": [
    {
      "label": "58-600",
      "value": "58-600",
      "unit": "",
      "appliesTo": "reinforcement bar callout, likely 58 bars at 600 spacing"
    }
  ],
  "notes": [],
  "labels": [
    "58-600 (2 BETWEEN EACH PAIR OF 400 BARS IN TOP OF SLAB OVER INTERMEDIATE BENTS)"
  ],
  "description": "This crop shows a partial longitudinal elevation of a bridge superstructure spanning over two intermediate bents and an end abutment, with the deck slab reinforcement pattern indicated by dot symbols along the top and bottom of the slab. A callout identifies additional top reinforcement bars (58-600) to be placed between pairs of 400 bars in the slab over the intermediate bents. The bents are shown with a tapered, flared-cap profile typical of pier column details."
}

{
  "view": "Cross Section",
  "objects": [
    {
      "name": "Deck slab",
      "tag": "2-800",
      "shape": "rectangular, cross-slope",
      "material": "reinforced concrete",
      "count": 1,
      "note": "labeled 2-800, cross slope 2% shown"
    },
    {
      "name": "Girder/Beam",
      "tag": "I-509",
      "shape": "I-section, tapered web",
      "material": "precast concrete",
      "count": 1,
      "note": "one of series of beams shown in section"
    },
    {
      "name": "Girder/Beam",
      "tag": "I-508",
      "shape": "I-section, tapered web",
      "material": "precast concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "Girder/Beam",
      "tag": "I-802",
      "shape": "I-section, tapered web",
      "material": "precast concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "Girder/Beam",
      "tag": "I-801",
      "shape": "I-section, tapered web",
      "material": "precast concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "Beam (unlabeled additional)",
      "tag": "",
      "shape": "I-section, tapered web",
      "material": "precast concrete",
      "count": 3,
      "note": "additional beams visible in section without individual callouts"
    },
    {
      "name": "Barrier/Parapet",
      "tag": "",
      "shape": "tapered vertical element",
      "material": "reinforced concrete",
      "count": 2,
      "note": "one at each edge of deck"
    },
    {
      "name": "Edge beam",
      "tag": "",
      "shape": "rectangular strip along deck edge",
      "material": "concrete",
      "count": 2,
      "note": "poured flush with outside face of beam per callout"
    },
    {
      "name": "Fence",
      "tag": "",
      "shape": "not shown",
      "material": "",
      "count": 0,
      "note": "noted as 'Fence not shown, typ.' - not depicted in this view"
    },
    {
      "name": "Bearing pad",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 0,
      "note": "noted as 'Bearing pads not shown'"
    }
  ],
  "measurements": [
    {
      "label": "Deck thickness",
      "value": "8",
      "unit": "in",
      "appliesTo": "deck slab (typ.)"
    },
    {
      "label": "Beam spacing",
      "value": "8-404",
      "unit": "",
      "appliesTo": "beam spacing dimension, at equal spaces"
    },
    {
      "label": "Edge offset",
      "value": "2",
      "unit": "in",
      "appliesTo": "edge dimension left of spacing group"
    },
    {
      "label": "Edge offset",
      "value": "2",
      "unit": "in",
      "appliesTo": "edge dimension right of spacing group"
    },
    {
      "label": "Cross slope",
      "value": "2",
      "unit": "%",
      "appliesTo": "deck cross slope"
    }
  ],
  "notes": [
    "SR 21 WB = PGL",
    "8-404 AT EQUAL SPACES",
    "8\", TYP.",
    "2%",
    "POUR EDGE BEAM FLUSH WITH OUTSIDE FACE OF BEAM, TYP.",
    "FENCE NOT SHOWN, TYP.",
    "NOTE: BEARING PADS NOT SHOWN"
  ],
  "labels": [
    "I-509",
    "I-508",
    "I-802",
    "I-801",
    "2-800",
    "SR 21 WB = PGL"
  ],
  "description": "This crop is a cross section through a bridge superstructure showing the deck slab, a series of precast I-shaped beams (tagged I-509, I-508, I-802, I-801) supporting the deck, and concrete parapets/barriers at each edge. It documents beam spacing, deck thickness, cross slope, the highway centerline (SR 21 WB = PGL), and callouts noting that bearing pads and a fence are not shown in this view, along with an edge beam pour detail."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "Endwall",
      "tag": "3'-0\" ENDWALL",
      "shape": "rectangular/tapered",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Shown in Section Thru Endwall at left side of deck"
    },
    {
      "name": "Endwall",
      "tag": "1'-6\" ENDWALL",
      "shape": "rectangular/tapered",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Shown in Section Thru Endwall, inboard of 3'-0\" endwall"
    },
    {
      "name": "Deck slab",
      "tag": "SLAB",
      "shape": "tapered, cross-slope 2%",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Spans full width shown, SR 21 WB = PGL centerline marked"
    },
    {
      "name": "Girder/Beam",
      "tag": "",
      "shape": "bulb-tee / I-section (PSC beam)",
      "material": "precast concrete",
      "count": 5,
      "note": "Repeating beam sections shown under deck slab; rebar marks 900A/900B point to beam tops"
    },
    {
      "name": "Preformed joint filler",
      "tag": "",
      "shape": "strip",
      "material": "preformed foam/elastomeric",
      "count": 3,
      "note": "1/2\" preformed joint filler (typ.) and 1\" preformed foam joint filler around pad"
    },
    {
      "name": "Construction joint",
      "tag": "",
      "shape": "linear joint",
      "material": "",
      "count": 1,
      "note": "Required construction joint parallel with deck, 1\" gap min."
    },
    {
      "name": "Barrier",
      "tag": "",
      "shape": "tapered/rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Shown in Fence Elevation and Fence Post Detail, supports fence"
    },
    {
      "name": "End post (fence)",
      "tag": "",
      "shape": "vertical pipe",
      "material": "galvanized/zinc coated steel",
      "count": 1,
      "note": ""
    },
    {
      "name": "Pull post (fence)",
      "tag": "",
      "shape": "2 7/8\" dia pipe",
      "material": "zinc coated steel",
      "count": 1,
      "note": ""
    },
    {
      "name": "Fence post (typical vertical)",
      "tag": "",
      "shape": "2 7/8\" dia pipe, curved top 45°",
      "material": "zinc coated steel",
      "count": null,
      "note": "Post spaced per Fence Notes 6, curved top detail with 2'-6\" R"
    },
    {
      "name": "Tension bar",
      "tag": "",
      "shape": "1 5/8\" dia pipe",
      "material": "zinc coated steel",
      "count": null,
      "note": ""
    },
    {
      "name": "Truss bracing",
      "tag": "",
      "shape": "diagonal 1 5/8\" dia pipe",
      "material": "zinc coated steel",
      "count": null,
      "note": "At end or pull post"
    },
    {
      "name": "Chain link fence fabric",
      "tag": "",
      "shape": "woven mesh",
      "material": "zinc coated steel, 9 gage",
      "count": 1,
      "note": "Security fence, 2 inch mesh"
    },
    {
      "name": "Pipe sleeve",
      "tag": "",
      "shape": "circular",
      "material": "galvanized steel",
      "count": 1,
      "note": "4\" dia. std. wt. pipe sleeve cast in barrier"
    },
    {
      "name": "End bent cap/section",
      "tag": "END BENT 1",
      "shape": "as detailed in Section at Endwall",
      "material": "reinforced concrete",
      "count": 1,
      "note": "End Bent 4 similar per note"
    },
    {
      "name": "Reinforcement bar",
      "tag": "900A",
      "shape": "bent bar",
      "material": "reinforcement steel",
      "count": null,
      "note": "4-900A called out at girder top"
    },
    {
      "name": "Reinforcement bar",
      "tag": "900B",
      "shape": "bent bar",
      "material": "reinforcement steel",
      "count": null,
      "note": "4-900B called out at girder tops, two locations"
    },
    {
      "name": "Reinforcement bar",
      "tag": "401",
      "shape": "bar",
      "material": "reinforcement steel",
      "count": null,
      "note": "4-401 shown in Section at Endwall; series not shown in main section per note"
    },
    {
      "name": "Reinforcement bar",
      "tag": "504A",
      "shape": "bar",
      "material": "reinforcement steel",
      "count": null,
      "note": "2-504A AT END"
    },
    {
      "name": "Reinforcement bar",
      "tag": "504B",
      "shape": "bar",
      "material": "reinforcement steel",
      "count": null,
      "note": "8-504B AT 12\"± BETWEEN BEAMS"
    },
    {
      "name": "Reinforcement bar",
      "tag": "505",
      "shape": "bar",
      "material": "reinforcement steel",
      "count": null,
      "note": "1-505 shown"
    },
    {
      "name": "Reinforcement bar",
      "tag": "506A",
      "shape": "bar",
      "material": "reinforcement steel",
      "count": null,
      "note": ""
    },
    {
      "name": "Reinforcement bar",
      "tag": "506B",
      "shape": "bar",
      "material": "reinforcement steel",
      "count": null,
      "note": "506B AT 18\"± ALT. TO GIVE 9\" SP."
    },
    {
      "name": "Bearing",
      "tag": "",
      "shape": "",
      "material": "",
      "count": null,
      "note": "Called out as 'BEARING NOT S[HOWN]' - not depicted, text partial/cut off"
    },
    {
      "name": "Slab reinforcement",
      "tag": "",
      "shape": "",
      "material": "reinforcement steel",
      "count": null,
      "note": "Noted as not shown in Section at Endwall"
    }
  ],
  "measurements": [
    {
      "label": "Overhang width",
      "value": "1 1/2",
      "unit": "in",
      "appliesTo": "Section Thru Endwall, left edge"
    },
    {
      "label": "Width",
      "value": "1'-8\"",
      "unit": "ft-in",
      "appliesTo": "Section Thru Endwall, left edge"
    },
    {
      "label": "Width",
      "value": "34'-0\"",
      "unit": "ft-in",
      "appliesTo": "Section Thru Endwall, main span"
    },
    {
      "label": "Width",
      "value": "6'-8\"",
      "unit": "ft-in",
      "appliesTo": "Section Thru Endwall, right side"
    },
    {
      "label": "Width",
      "value": "1'-1\"",
      "unit": "ft-in",
      "appliesTo": "Section Thru Endwall, right edge"
    },
    {
      "label": "Barrier height at right",
      "value": "3'-6\"",
      "unit": "ft-in",
      "appliesTo": "Section Thru Endwall right barrier"
    },
    {
      "label": "Cross slope",
      "value": "2",
      "unit": "%",
      "appliesTo": "Deck slab"
    },
    {
      "label": "Gap min.",
      "value": "1",
      "unit": "in",
      "appliesTo": "Construction joint at deck"
    },
    {
      "label": "Joint filler thickness",
      "value": "1/2",
      "unit": "in",
      "appliesTo": "Preformed joint filler, typical"
    },
    {
      "label": "Joint filler thickness",
      "value": "1",
      "unit": "in",
      "appliesTo": "Preformed foam joint filler around pad"
    },
    {
      "label": "Post spacing max",
      "value": "12",
      "unit": "in",
      "appliesTo": "Tension bar bands O.C. max"
    },
    {
      "label": "Pipe diameter",
      "value": "1 5/8",
      "unit": "in",
      "appliesTo": "Tension bar/truss bracing pipe, zinc coated"
    },
    {
      "label": "Pipe diameter",
      "value": "2 7/8",
      "unit": "in",
      "appliesTo": "Fence pipe, typical"
    },
    {
      "label": "Pull post width",
      "value": "2 7/8",
      "unit": "in",
      "appliesTo": "Pull post diameter"
    },
    {
      "label": "Offset",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "Fence elevation, base dimension"
    },
    {
      "label": "Offset",
      "value": "1/2",
      "unit": "in",
      "appliesTo": "Offset dimension in fence elevation"
    },
    {
      "label": "Fence height",
      "value": "5'-1\"",
      "unit": "ft-in",
      "appliesTo": "Fence Post Detail"
    },
    {
      "label": "Fence height",
      "value": "4'-7\"",
      "unit": "ft-in",
      "appliesTo": "Fence Post Detail"
    },
    {
      "label": "Total height",
      "value": "10'-4\"",
      "unit": "ft-in",
      "appliesTo": "Fence Post Detail total"
    },
    {
      "label": "Fence height",
      "value": "7'-0\"",
      "unit": "ft-in",
      "appliesTo": "Zinc coated fence height"
    },
    {
      "label": "Base height",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "Fence Post Detail base"
    },
    {
      "label": "Barrier height",
      "value": "3'-6\"",
      "unit": "ft-in",
      "appliesTo": "Fence Post Detail barrier"
    },
    {
      "label": "Curve radius",
      "value": "2'-6\"",
      "unit": "ft-in",
      "appliesTo": "Fence Post Detail curved top, R"
    },
    {
      "label": "Angle",
      "value": "45",
      "unit": "degrees",
      "appliesTo": "Fence Post Detail curved top"
    },
    {
      "label": "Offset dimension",
      "value": "10 1/4\"",
      "unit": "in",
      "appliesTo": "Fence Post Detail"
    },
    {
      "label": "Pipe sleeve diameter",
      "value": "4",
      "unit": "in",
      "appliesTo": "Pipe sleeve, std wt"
    },
    {
      "label": "Section at Endwall width",
      "value": "12\"",
      "unit": "in",
      "appliesTo": "Section at Endwall top dimension"
    },
    {
      "label": "Section at Endwall width",
      "value": "1'-6\"",
      "unit": "ft-in",
      "appliesTo": "Section at Endwall"
    },
    {
      "label": "Section at Endwall width",
      "value": "8\"",
      "unit": "in",
      "appliesTo": "Section at Endwall"
    },
    {
      "label": "Radius",
      "value": "1/4\"",
      "unit": "in",
      "appliesTo": "Section at Endwall, R"
    },
    {
      "label": "Clear cover",
      "value": "3 1/2",
      "unit": "in min",
      "appliesTo": "Section at Endwall min. clearance"
    },
    {
      "label": "Depth",
      "value": "10\"",
      "unit": "in",
      "appliesTo": "Section at Endwall"
    },
    {
      "label": "Depth",
      "value": "9\"",
      "unit": "in",
      "appliesTo": "Section at Endwall"
    },
    {
      "label": "Depth",
      "value": "12\"",
      "unit": "in",
      "appliesTo": "Section at Endwall"
    },
    {
      "label": "Depth",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "Section at Endwall"
    },
    {
      "label": "Clearance",
      "value": "2\" CL. 3 SIDES",
      "unit": "in",
      "appliesTo": "Section at Endwall reinforcement clearance"
    },
    {
      "label": "Spacing",
      "value": "8\"",
      "unit": "in",
      "appliesTo": "Section at Endwall dimension near 506A"
    },
    {
      "label": "Bar spacing",
      "value": "18\"±",
      "unit": "in",
      "appliesTo": "506B bar spacing"
    },
    {
      "label": "Alt spacing",
      "value": "9\"",
      "unit": "in",
      "appliesTo": "506B alternate spacing"
    },
    {
      "label": "Bar spacing",
      "value": "12\"±",
      "unit": "in",
      "appliesTo": "504B bar spacing between beams"
    },
    {
      "label": "Post fastening interval max",
      "value": "14",
      "unit": "in",
      "appliesTo": "Fence fabric fastening (Fence Note 5)"
    },
    {
      "label": "Post spacing min",
      "value": "7'-0\"",
      "unit": "ft-in",
      "appliesTo": "Fence post spacing minimum (Fence Note 6)"
    },
    {
      "label": "Post spacing max",
      "value": "10'-0\"",
      "unit": "ft-in",
      "appliesTo": "Fence post spacing maximum (Fence Note 6)"
    },
    {
      "label": "Post distance from joint",
      "value": "1'-0\"",
      "unit": "ft-in min",
      "appliesTo": "Fence post minimum distance from barrier joints (Fence Note 6)"
    }
  ],
  "notes": [
    "NOTE: BARS 401, 504 SERIES, 505, AND 506 SERIES NOT SHOWN",
    "FENCE NOTES:",
    "1. FENCE SHALL BE 9 GAGE CHAIN LINK ZINC COATED TWO INCH SECURITY FENCE.",
    "2. CAST 4\" DIA. GALVANIZED SLEEVE IN THE PARAPET. ALLOW NON-SHRINK, NON-METALLIC GROUT TO CURE FOR THREE DAYS BEFORE FENCE FABRIC IS INSTALLED.",
    "3. APPLY GALVANIZING REPAIR COMPOUND, IN ACCORDANCE WITH GEORGIA DOT SPECIFICATION 645, TO ENDS OF 4\" DIA. GALVANIZED SLEEVES.",
    "4. PROVIDE EXPANSION SLEEVE FOR ALL RAILS TO MATCH SUPERSTRUCTURE JOINTS.",
    "5. FASTEN FABRIC TO POSTS AT INTERVALS NOT GREATER THAN 14\".",
    "6. SPACE POSTS AT A MINIMUM OF 7'-0\" AND A MAXIMUM OF 10'-0\". PLACE POSTS 1'-0\" MINIMUM FROM JOINTS IN BARRIER. SEE DECK PLAN FOR POST SPACING.",
    "7. FOR FURTHER DETAILS, SEE GEORGIA DOT SPECIFICATIONS SECTIONS 643 AND 894.",
    "WATERPROOFING, SEE SECTION 530 OF THE GEORGIA DOT SPECIFICATIONS",
    "SLAB REINFORCEMENT NOT SHOWN",
    "END BENT 1 SHOWN, END BENT 4 SIMILAR",
    "* NON-SHRINK, NON-METALLIC PORTLAND CEMENT GROUT IN ACCORDANCE WITH ASTM C1107, TROWEL TO PROVIDE POSITIVE DRAINAGE.",
    "REQUIRED CONSTRUCTION JOINT PARALLEL WITH DECK, TYP."
  ],
  "labels": [
    "SECTION THRU ENDWALL",
    "(LOOKING AHEAD, LEFT BRIDGE SHOWN, RIGHT BRIDGE SIMILAR)",
    "FENCE ELEVATION",
    "SCALE: 3/4\" = 1'-0\"",
    "FENCE POST DETAIL",
    "SECTION AT ENDWALL",
    "SCALE: 3/4\" = 1'-0\"",
    "SR 21 WB = PGL",
    "END POST",
    "CONST. JOINT",
    "BARRIER",
    "SLAB",
    "ZINC COATED FENCE",
    "TENSION BAR BANDS AT 12\" O.C. MAX.",
    "TENSION BAR ZINC COATED",
    "1 5/8\" DIA. PIPE ZINC COATED",
    "2 7/8\" DIA. PIPE, TYP.",
    "TRUSS BRACING AT END OR PULL",
    "POST VERT. ZINC COATED",
    "2 7/8\" PULL POST",
    "1/2\" OFFSET",
    "4\" DIA. STD. WT. PIPE SLEEVE",
    "7'-0\" ZINC COATED FENCE",
    "2 7/8\" DIA. PIPE"
  ],
  "description": "This sheet contains four related details for a bridge structure: a full-width Section Thru Endwall showing the deck cross-slope, precast beams, endwalls and joint fillers with rebar callouts 900A/900B; a Fence Elevation and Fence Post Detail showing chain link security fence construction with tension bars, truss bracing, and post dimensions atop a concrete barrier; and a Section at Endwall (End Bent 1, similar at End Bent 4) showing end bent reinforcement details (bars 900, 401, 504A, 504B, 506A, 506B, 505) with bearing area and waterproofing notes. It documents deck cross-section geometry, endwall/joint details, security fence construction requirements per Georgia DOT specifications, and end bent reinforcement layout for the barrier and beam seat area."
}

{
  "view": "Detail",
  "objects": [
    {
      "name": "Endwall",
      "tag": "3'-0\" ENDWALL",
      "shape": "rectangular/tapered",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Larger endwall shown at left of section thru endwall"
    },
    {
      "name": "Endwall",
      "tag": "1'-6\" ENDWALL",
      "shape": "rectangular/tapered",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Smaller endwall shown at right side of deck"
    },
    {
      "name": "Girder",
      "tag": "",
      "shape": "I-girder",
      "material": "structural steel or precast concrete",
      "count": 6,
      "note": "Repeated girder sections shown in Section Thru Endwall"
    },
    {
      "name": "Deck slab",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "Reinforcement bar",
      "tag": "4-900B",
      "shape": "",
      "material": "reinforced steel",
      "count": 2,
      "note": "Located at each endwall"
    },
    {
      "name": "Reinforcement bar",
      "tag": "4-900A",
      "shape": "",
      "material": "reinforced steel",
      "count": 1,
      "note": "Located mid-span area of section"
    },
    {
      "name": "Preformed joint filler",
      "tag": "",
      "shape": "strip",
      "material": "preformed elastomeric material",
      "count": 3,
      "note": "1/2\" and 1\" thicknesses noted at joints and around pad"
    },
    {
      "name": "Construction joint",
      "tag": "",
      "shape": "linear",
      "material": "",
      "count": 1,
      "note": "Required construction joint parallel with deck"
    },
    {
      "name": "Barrier",
      "tag": "",
      "shape": "tapered/rectangular",
      "material": "reinforced concrete",
      "count": 2,
      "note": "Shown in Fence Elevation and Fence Post Detail atop slab"
    },
    {
      "name": "Fence",
      "tag": "",
      "shape": "chain link with pipe posts",
      "material": "zinc coated steel",
      "count": 1,
      "note": "9 gage chain link security fence per notes"
    },
    {
      "name": "Fence post",
      "tag": "",
      "shape": "pipe, curved top",
      "material": "zinc coated steel",
      "count": 1,
      "note": "2 7/8\" dia. pipe pull post with truss bracing"
    },
    {
      "name": "Pipe sleeve",
      "tag": "",
      "shape": "circular",
      "material": "galvanized steel",
      "count": 1,
      "note": "4\" dia. std. wt. pipe sleeve cast in parapet"
    },
    {
      "name": "Tension bar",
      "tag": "",
      "shape": "linear",
      "material": "zinc coated steel",
      "count": 1,
      "note": "Tension bar bands at 12\" o.c. max."
    },
    {
      "name": "Truss bracing",
      "tag": "",
      "shape": "diagonal",
      "material": "zinc coated steel",
      "count": 1,
      "note": "At end or pull post"
    },
    {
      "name": "End Bent",
      "tag": "END BENT 1 / END BENT 4",
      "shape": "",
      "material": "reinforced concrete",
      "count": 1,
      "note": "Section at Endwall shows End Bent 1; End Bent 4 similar per note"
    },
    {
      "name": "Reinforcement bar",
      "tag": "1-505",
      "shape": "",
      "material": "reinforced steel",
      "count": 1,
      "note": "Shown in Section at Endwall"
    },
    {
      "name": "Reinforcement bar",
      "tag": "506B",
      "shape": "",
      "material": "reinforced steel",
      "count": 1,
      "note": "At 18\" spacing, alt. to give 9\" sp."
    },
    {
      "name": "Reinforcement bar",
      "tag": "506A",
      "shape": "",
      "material": "reinforced steel",
      "count": 1,
      "note": ""
    },
    {
      "name": "Reinforcement bar",
      "tag": "4-900",
      "shape": "",
      "material": "reinforced steel",
      "count": 1,
      "note": ""
    },
    {
      "name": "Reinforcement bar",
      "tag": "8-504B",
      "shape": "",
      "material": "reinforced steel",
      "count": 1,
      "note": "At 12\"± between beams"
    },
    {
      "name": "Reinforcement bar",
      "tag": "2-504A",
      "shape": "",
      "material": "reinforced steel",
      "count": 1,
      "note": "At end of beam (text cut off)"
    },
    {
      "name": "Reinforcement bar",
      "tag": "4-401",
      "shape": "",
      "material": "reinforced steel",
      "count": 1,
      "note": ""
    },
    {
      "name": "Bearing",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 1,
      "note": "Labeled 'BEARING NOT SH[OWN]', partially cut off"
    },
    {
      "name": "Waterproofing",
      "tag": "",
      "shape": "",
      "material": "per Section 530 Georgia DOT Specifications",
      "count": null,
      "note": "Callout only, not detailed as an item"
    }
  ],
  "measurements": [
    {
      "label": "Width",
      "value": "1 1/2",
      "unit": "in",
      "appliesTo": "gap at left edge of section"
    },
    {
      "label": "Width",
      "value": "1'-8\"",
      "unit": "ft-in",
      "appliesTo": "left endwall region"
    },
    {
      "label": "Length",
      "value": "34'-0\"",
      "unit": "ft-in",
      "appliesTo": "deck section thru endwall span"
    },
    {
      "label": "Width",
      "value": "6'-8\"",
      "unit": "ft-in",
      "appliesTo": "right side of deck near endwall"
    },
    {
      "label": "Width",
      "value": "1'-1\"",
      "unit": "ft-in",
      "appliesTo": "right edge of section"
    },
    {
      "label": "Height",
      "value": "3'-6\"",
      "unit": "ft-in",
      "appliesTo": "right endwall parapet height"
    },
    {
      "label": "Slope",
      "value": "2%",
      "unit": "%",
      "appliesTo": "deck cross slope"
    },
    {
      "label": "Gap",
      "value": "1\"",
      "unit": "in",
      "appliesTo": "required construction joint gap, min."
    },
    {
      "label": "Joint filler thickness",
      "value": "1/2\"",
      "unit": "in",
      "appliesTo": "preformed joint filler, typ."
    },
    {
      "label": "Joint filler thickness",
      "value": "1\"",
      "unit": "in",
      "appliesTo": "preformed foam joint filler around pad"
    },
    {
      "label": "Endwall height",
      "value": "3'-0\"",
      "unit": "ft-in",
      "appliesTo": "3'-0\" ENDWALL"
    },
    {
      "label": "Endwall height",
      "value": "1'-6\"",
      "unit": "ft-in",
      "appliesTo": "1'-6\" ENDWALL"
    },
    {
      "label": "Fence fabric interval",
      "value": "14",
      "unit": "in",
      "appliesTo": "fence fastening interval, max"
    },
    {
      "label": "Post spacing minimum",
      "value": "7'-0\"",
      "unit": "ft-in",
      "appliesTo": "fence posts, min."
    },
    {
      "label": "Post spacing maximum",
      "value": "10'-0\"",
      "unit": "ft-in",
      "appliesTo": "fence posts, max."
    },
    {
      "label": "Post offset from joint",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "fence posts min from barrier joints"
    },
    {
      "label": "Tension bar band spacing",
      "value": "12\"",
      "unit": "in",
      "appliesTo": "tension bar bands o.c. max."
    },
    {
      "label": "Pipe diameter",
      "value": "1 5/8\"",
      "unit": "in",
      "appliesTo": "pipe, zinc coated (fence)"
    },
    {
      "label": "Pipe diameter",
      "value": "2 7/8\"",
      "unit": "in",
      "appliesTo": "pipe, typ. (fence posts)"
    },
    {
      "label": "Offset",
      "value": "1/2\"",
      "unit": "in",
      "appliesTo": "offset dimension in fence elevation"
    },
    {
      "label": "Distance",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "end post/const joint spacing"
    },
    {
      "label": "Radius",
      "value": "2'-6\"",
      "unit": "ft-in",
      "appliesTo": "fence post curve radius"
    },
    {
      "label": "Angle",
      "value": "45°",
      "unit": "degrees",
      "appliesTo": "fence post bend angle"
    },
    {
      "label": "Dimension",
      "value": "10 1/4\"",
      "unit": "in",
      "appliesTo": "fence post detail"
    },
    {
      "label": "Height",
      "value": "5'-1\"",
      "unit": "ft-in",
      "appliesTo": "fence post detail"
    },
    {
      "label": "Height",
      "value": "4'-7\"",
      "unit": "ft-in",
      "appliesTo": "fence post height"
    },
    {
      "label": "Height",
      "value": "10'-4\"",
      "unit": "ft-in",
      "appliesTo": "overall fence post detail height"
    },
    {
      "label": "Fence height",
      "value": "7'-0\"",
      "unit": "ft",
      "appliesTo": "zinc coated fence"
    },
    {
      "label": "Distance",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "fence post detail lower dimension"
    },
    {
      "label": "Barrier height",
      "value": "3'-6\"",
      "unit": "ft-in",
      "appliesTo": "barrier in fence post detail"
    },
    {
      "label": "Pipe sleeve diameter",
      "value": "4\"",
      "unit": "in",
      "appliesTo": "pipe sleeve, std wt."
    },
    {
      "label": "Clear cover",
      "value": "2\"",
      "unit": "in",
      "appliesTo": "CL. 3 SIDES, section at endwall"
    },
    {
      "label": "Minimum clearance",
      "value": "3 1/2\"",
      "unit": "in",
      "appliesTo": "506B min. clearance"
    },
    {
      "label": "Dimension",
      "value": "12\"",
      "unit": "in",
      "appliesTo": "section at endwall top dimension"
    },
    {
      "label": "Dimension",
      "value": "1'-6\"",
      "unit": "ft-in",
      "appliesTo": "section at endwall dimension"
    },
    {
      "label": "Dimension",
      "value": "8\"",
      "unit": "in",
      "appliesTo": "section at endwall dimension"
    },
    {
      "label": "Dimension",
      "value": "10\"",
      "unit": "in",
      "appliesTo": "section at endwall vertical dimension"
    },
    {
      "label": "Dimension",
      "value": "9\"",
      "unit": "in",
      "appliesTo": "section at endwall vertical dimension"
    },
    {
      "label": "Dimension",
      "value": "12\"",
      "unit": "in",
      "appliesTo": "section at endwall vertical dimension"
    },
    {
      "label": "Dimension",
      "value": "1'-0\"",
      "unit": "ft-in",
      "appliesTo": "section at endwall lower dimension"
    },
    {
      "label": "Spacing",
      "value": "18\"",
      "unit": "in",
      "appliesTo": "506B rebar spacing, approx."
    },
    {
      "label": "Spacing",
      "value": "9\"",
      "unit": "in",
      "appliesTo": "506B alt. spacing to give"
    },
    {
      "label": "Spacing",
      "value": "12\"",
      "unit": "in",
      "appliesTo": "8-504B spacing between beams, approx."
    },
    {
      "label": "Radius",
      "value": "1/4\"",
      "unit": "in",
      "appliesTo": "corner radius, section at endwall"
    },
    {
      "label": "Scale",
      "value": "3/4\" = 1'-0\"",
      "unit": "",
      "appliesTo": "Fence Elevation, Fence Post Detail, Section at Endwall"
    }
  ],
  "notes": [
    "NOTE: BARS 401, 504 SERIES, 505, AND 506 SERIES NOT SHOWN",
    "FENCE NOTES:",
    "1. FENCE SHALL BE 9 GAGE CHAIN LINK ZINC COATED TWO INCH SECURITY FENCE.",
    "2. CAST 4\" DIA. GALVANIZED SLEEVE IN THE PARAPET. ALLOW NON-SHRINK, NON-METALLIC GROUT TO CURE FOR THREE DAYS BEFORE FENCE FABRIC IS INSTALLED.",
    "3. APPLY GALVANIZING REPAIR COMPOUND, IN ACCORDANCE WITH GEORGIA DOT SPECIFICATION 645, TO ENDS OF 4\" DIA. GALVANIZED SLEEVES.",
    "4. PROVIDE EXPANSION SLEEVE FOR ALL RAILS TO MATCH SUPERSTRUCTURE JOINTS.",
    "5. FASTEN FABRIC TO POSTS AT INTERVALS NOT GREATER THAN 14\".",
    "6. SPACE POSTS AT A MINIMUM OF 7'-0\" AND A MAXIMUM OF 10'-0\". PLACE POSTS 1'-0\" MINIMUM FROM JOINTS IN BARRIER. SEE DECK PLAN FOR POST SPACING.",
    "7. FOR FURTHER DETAILS, SEE GEORGIA DOT SPECIFICATIONS SECTIONS 643 AND 894.",
    "WATERPROOFING, SEE SECTION 530 OF THE GEORGIA DOT SPECIFICATIONS",
    "SLAB REINFORCEMENT NOT SHOWN",
    "* NON-SHRINK, NON-METALLIC PORTLAND CEMENT GROUT IN ACCORDANCE WITH ASTM C1107, TROWEL TO PROVIDE POSITIVE DRAINAGE.",
    "END BENT 1 SHOWN, END BENT 4 SIMILAR"
  ],
  "labels": [
    "SECTION THRU ENDWALL",
    "(LOOKING AHEAD, LEFT BRIDGE SHOWN, RIGHT BRIDGE SIMILAR)",
    "SR 21 WB = PGL",
    "FENCE ELEVATION",
    "FENCE POST DETAIL",
    "SECTION AT ENDWALL",
    "SCALE: 3/4\" = 1'-0\"",
    "BARRIER",
    "SLAB",
    "END POST",
    "CONST. JOINT",
    "TENSION BAR ZINC COATED",
    "ZINC COATED FENCE",
    "POST VERT. ZINC COATED",
    "TRUSS BRACING AT END OR PULL",
    "2 7/8\" PULL POST",
    "4\" DIA. STD. WT. PIPE SLEEVE",
    "7'-0\" ZINC COATED FENCE",
    "BEARING NOT SH[OWN]"
  ],
  "description": "This crop contains multiple bridge structural details: a full-width cross section thru an endwall showing girders, deck slab, endwall heights, and joint fillers with rebar marks (4-900A/B); a set of fence notes governing chain link security fence construction; a fence elevation and fence post detail showing pipe post dimensions and bracing; and a section at the endwall (End Bent 1/4) showing reinforcement bars, bearing area (not shown), and waterproofing callout. The sheet appears to document both superstructure endwall/deck geometry and appurtenant fence/security barrier details for a bridge, likely along SR 21."
}

{
  "view": "Cross Section",
  "objects": [
    {
      "name": "Deck slab",
      "tag": "",
      "shape": "flat with 2% cross slope",
      "material": "reinforced concrete",
      "count": 1,
      "note": "7 3/4\" thick between beams, 8\" in overhangs"
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 1 through BEAM 6",
      "shape": "bulb-tee / I-section (tapered web)",
      "material": "precast concrete",
      "count": 6,
      "note": "spaced at 7'-6\" typical"
    },
    {
      "name": "Diaphragm",
      "tag": "",
      "shape": "rectangular between beams",
      "material": "reinforced concrete",
      "count": 5,
      "note": "shown in Section Thru Diaphragm, with reinforcement 7-403B, 4-402B, 2-507B"
    },
    {
      "name": "Fence",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 2,
      "note": "noted as 'FENCE NOT SHOWN, TYP.' at both bridge edges"
    },
    {
      "name": "Reinforcement bar",
      "tag": "502",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": null,
      "note": "at every 500A"
    },
    {
      "name": "Reinforcement bar",
      "tag": "500A",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": null,
      "note": "spaced at 6 3/4\""
    },
    {
      "name": "Reinforcement bar",
      "tag": "501",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": null,
      "note": "under every 500A"
    },
    {
      "name": "Reinforcement bar",
      "tag": "400B and C",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": null,
      "note": "30 total spaced as shown across slab; also 6 and 13 bar groups at ends/middle spans"
    },
    {
      "name": "Reinforcement bar",
      "tag": "403B",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": 7,
      "note": "at equal spaces, in diaphragm section"
    },
    {
      "name": "Reinforcement bar",
      "tag": "402B",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": 4,
      "note": "in diaphragm section"
    },
    {
      "name": "Reinforcement bar",
      "tag": "507B",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": 2,
      "note": "appears twice in diaphragm section (2 sets of 2)"
    },
    {
      "name": "Plain bar",
      "tag": "",
      "shape": "round, 1\" diameter",
      "material": "plain steel bar",
      "count": null,
      "note": "labeled '1\" DIAMETER PLAIN BAR' in diaphragm section"
    },
    {
      "name": "Drip bead",
      "tag": "",
      "shape": "triangular",
      "material": "",
      "count": 1,
      "note": "3/4\" triangular drip bead full length of bridge, typ., at deck edge"
    },
    {
      "name": "Construction joint",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 1,
      "note": "required construction joint parallel with deck, typ."
    }
  ],
  "measurements": [
    {
      "label": "Out to out width",
      "value": "43'-7\"",
      "unit": "",
      "appliesTo": "deck slab"
    },
    {
      "label": "Gutter to gutter width",
      "value": "40'-0\"",
      "unit": "",
      "appliesTo": "deck slab"
    },
    {
      "label": "Width between fence lines",
      "value": "34'-0\"",
      "unit": "",
      "appliesTo": "deck slab"
    },
    {
      "label": "Distance from PGL to edge",
      "value": "22'-0\"",
      "unit": "",
      "appliesTo": "deck slab"
    },
    {
      "label": "Distance PGL to point",
      "value": "6'-0\"",
      "unit": "",
      "appliesTo": "deck slab"
    },
    {
      "label": "Min shoulder/clear width",
      "value": "3'-0\"",
      "unit": "MIN.",
      "appliesTo": "deck slab, near right edge"
    },
    {
      "label": "Edge overhang dimension",
      "value": "1'-8\"",
      "unit": "",
      "appliesTo": "deck slab overhang, both sides"
    },
    {
      "label": "Edge thickness",
      "value": "1 1/2\"",
      "unit": "",
      "appliesTo": "deck slab edge, both sides"
    },
    {
      "label": "Beam top height typ.",
      "value": "8\"",
      "unit": "",
      "appliesTo": "beam, typ., both sides"
    },
    {
      "label": "Drip bead offset",
      "value": "3\"",
      "unit": "",
      "appliesTo": "deck edge, right side"
    },
    {
      "label": "Construction joint offset",
      "value": "8\"",
      "unit": "",
      "appliesTo": "deck edge, right side"
    },
    {
      "label": "Slab thickness",
      "value": "7 3/4\"",
      "unit": "",
      "appliesTo": "deck slab, between beams"
    },
    {
      "label": "Clear cover",
      "value": "2 1/4\"",
      "unit": "CL.",
      "appliesTo": "deck slab top reinforcement"
    },
    {
      "label": "Clear cover",
      "value": "1\"",
      "unit": "CL.",
      "appliesTo": "deck slab bottom reinforcement"
    },
    {
      "label": "Cross slope",
      "value": "2",
      "unit": "%",
      "appliesTo": "deck slab"
    },
    {
      "label": "Beam spacing",
      "value": "7'-6\"",
      "unit": "",
      "appliesTo": "BEAM 1 to BEAM 6, typical spacing, 5 spaces shown"
    },
    {
      "label": "Overhang end dimension",
      "value": "3'-0 1/2\"",
      "unit": "",
      "appliesTo": "deck slab, both ends"
    },
    {
      "label": "Rebar group spacing",
      "value": "3\"",
      "unit": "",
      "appliesTo": "400B and C bars, typ. at multiple locations"
    },
    {
      "label": "Edge stirrup spacing",
      "value": "4 3/8\"",
      "unit": "",
      "appliesTo": "6-400B and C group, both ends"
    },
    {
      "label": "500A bar spacing",
      "value": "6 3/4\"",
      "unit": "",
      "appliesTo": "500A bars"
    },
    {
      "label": "400B and C bar count",
      "value": "30",
      "unit": "",
      "appliesTo": "400B and C, spaced as shown"
    },
    {
      "label": "400B and C bar count",
      "value": "6",
      "unit": "",
      "appliesTo": "400B and C at eq. sps, near ends"
    },
    {
      "label": "400B and C bar count",
      "value": "13",
      "unit": "",
      "appliesTo": "400B and C at equal spaces, typ., middle spans"
    },
    {
      "label": "D dimension - interior beams",
      "value": "8 3/4\"",
      "unit": "",
      "appliesTo": "D, interior beams"
    },
    {
      "label": "D dimension - exterior beams",
      "value": "9 1/4\"",
      "unit": "",
      "appliesTo": "D, exterior beams"
    },
    {
      "label": "403B rebar count",
      "value": "7",
      "unit": "",
      "appliesTo": "403B, diaphragm section"
    },
    {
      "label": "403B end offset",
      "value": "5\"",
      "unit": "",
      "appliesTo": "403B, diaphragm section, both sides"
    },
    {
      "label": "402B rebar count",
      "value": "4",
      "unit": "",
      "appliesTo": "402B, diaphragm section"
    },
    {
      "label": "507B rebar count",
      "value": "2",
      "unit": "",
      "appliesTo": "507B, diaphragm section, each occurrence"
    },
    {
      "label": "Cross slope",
      "value": "2",
      "unit": "%",
      "appliesTo": "diaphragm section"
    }
  ],
  "notes": [
    "DIMENSION \"D\" IS MEASURED FROM TOP OF SLAB TO TOP OF BEAMS AT CENTERLINE BEARING. VARY \"D\" BETWEEN BEARINGS TO COMPENSATE FOR DEAD LOAD DEFLECTION, AND VERTICAL CURVE.",
    "MAINTAIN A CONSTANT SLAB THICKNESS OF 7 3/4\" BETWEEN BEAMS AND 8\" IN THE OVERHANGS.",
    "\"D\" = 8 3/4\" INTERIOR BEAMS",
    "\"D\" = 9 1/4\" EXTERIOR BEAMS",
    "FENCE NOT SHOWN, TYP.",
    "30-400B AND C SPACED AS SHOWN",
    "502 AT EVERY 500A, TYP.",
    "500A AT 6 3/4\"",
    "501 UNDER EVERY 500A",
    "13-400B AND C AT EQUAL SPACES, TYP.",
    "6-400B AND C AT EQ. SPS.",
    "REQUIRED CONSTRUCTION JOINT PARALLEL WITH DECK, TYP.",
    "¾\" TRIANGULAR DRIP BEAD FULL LENGTH OF BRIDGE, TYP.",
    "7-403B AT EQUAL SPACES",
    "1\" DIAMETER PLAIN BAR"
  ],
  "labels": [
    "SECTION THRU SLAB",
    "SECTION THRU DIAPHRAGM",
    "SR 21 WB = PGL",
    "C BEAM 1",
    "C BEAM 2",
    "C BEAM 3",
    "C BEAM 4",
    "C BEAM 5",
    "C BEAM 6"
  ],
  "description": "This crop shows two cross sections of a precast concrete beam bridge superstructure: an upper 'Section Thru Slab' depicting the full deck width with six PSC beams (Beam 1 through Beam 6), slab reinforcement details, overhangs, fence notes, and dimension callouts including deck widths, slab thicknesses, clear cover, and beam spacing; and a lower 'Section Thru Diaphragm' showing the intermediate diaphragms between beams with reinforcement bars 403B, 402B, 507B, and a 1\" diameter plain bar. Together these views document the deck slab geometry, beam layout, cross slope, and diaphragm reinforcement for this bridge structure."
}

{
  "view": "Section",
  "objects": [
    {
      "name": "PSC beam",
      "tag": "I-508",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 1,
      "note": "labeled beam among the row of bulb-tee/I-shaped beams"
    },
    {
      "name": "PSC beam",
      "tag": "I-509",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "PSC beam",
      "tag": "I-801",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 1,
      "note": "lower flange callout, likely same girder line as I-509"
    },
    {
      "name": "PSC beam",
      "tag": "I-802",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 1,
      "note": "lower flange callout, likely same girder line as I-508"
    },
    {
      "name": "beam/deck edge element",
      "tag": "2-800",
      "shape": "tapered/edge",
      "material": "concrete",
      "count": 1,
      "note": "labeled at deck edge near fence"
    },
    {
      "name": "PSC beam (unlabeled)",
      "tag": "",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 3,
      "note": "three additional similar beams shown without individual callouts, part of the beam line at equal spacing 8-404"
    },
    {
      "name": "deck slab",
      "tag": "",
      "shape": "tapered/sloped",
      "material": "reinforced concrete",
      "count": 1,
      "note": "deck poured over beams with 2% slope shown"
    },
    {
      "name": "edge beam / barrier curb",
      "tag": "",
      "shape": "tapered upstand",
      "material": "reinforced concrete",
      "count": 2,
      "note": "end upstands at left and right edges, one noted with fence detail"
    },
    {
      "name": "bearing pad (not shown)",
      "tag": "",
      "shape": "",
      "material": "",
      "count": null,
      "note": "explicitly noted as not shown in this section"
    },
    {
      "name": "fence",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 0,
      "note": "noted as not shown, typical, only callout arrow present"
    }
  ],
  "measurements": [
    {
      "label": "edge distance",
      "value": "2",
      "unit": "in",
      "appliesTo": "left side of beam spacing group"
    },
    {
      "label": "edge distance",
      "value": "2",
      "unit": "in",
      "appliesTo": "right side of beam spacing group"
    },
    {
      "label": "beam spacing dimension",
      "value": "8-404",
      "unit": "",
      "appliesTo": "beam spacing group, at equal spaces"
    },
    {
      "label": "cross slope",
      "value": "2",
      "unit": "%",
      "appliesTo": "deck surface"
    }
  ],
  "notes": [
    "NOTE: BEARING PADS NOT SHOWN",
    "DO NOT REMOVE EDGE BEAM FORMS UNTIL 72 HOURS AFTER THE DECK POUR IS COMPLETED OR DECK REACHES 28 DAY CONCRETE STRENGTH.",
    "FENCE NOT SHOWN, TYP.",
    "POUR EDGE BEAM FLUSH WITH OUTSIDE FACE OF BEAM, TYP.",
    "8-404 AT EQUAL SPACES"
  ],
  "labels": [
    "SECTION THRU EDGE BEAM",
    "SR 21 WB = PGL",
    "I-508",
    "I-509",
    "I-801",
    "I-802",
    "2-800"
  ],
  "description": "This crop is a cross-section titled 'SECTION THRU EDGE BEAM' showing a transverse slice through a bridge superstructure at the edge beam location, with a row of precast concrete I-shaped/bulb-tee beams supporting a sloped deck slab (2% cross slope) and edge upstand/curb elements at each end. Beam spacing is dimensioned as '8-404 AT EQUAL SPACES' with 2-inch edge offsets, and individual beam and flange callouts (I-508, I-509, I-801, I-802, 2-800) identify specific structural pieces, while notes address bearing pad omission, edge beam form removal timing, and an unshown fence at the right edge."
}

{
  "view": "Cross Section",
  "objects": [
    {
      "name": "Deck slab",
      "tag": "",
      "shape": "tapered/crowned rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "7¾\" thick between beams, 8\" thick in overhangs, 2% cross slope"
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 1",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": "centerline shown, 7'-6\" spacing"
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 2",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 3",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 4",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 5",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "PSC beam",
      "tag": "BEAM 6",
      "shape": "bulb-tee/I-section (tapered web)",
      "material": "precast concrete",
      "count": 1,
      "note": ""
    },
    {
      "name": "Diaphragm",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 5,
      "note": "shown between beams in Section Thru Diaphragm, with 7-403B bars at equal spaces and 1\" diameter plain bar"
    },
    {
      "name": "Fence",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 0,
      "note": "labeled 'FENCE NOT SHOWN, TYP.' at both edges — present but not drawn"
    },
    {
      "name": "Reinforcement bar",
      "tag": "502",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": null,
      "note": "placed at every 500A, typ."
    },
    {
      "name": "Reinforcement bar",
      "tag": "500A",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": null,
      "note": "spaced at 6¾\""
    },
    {
      "name": "Reinforcement bar",
      "tag": "501",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": null,
      "note": "under every 500A"
    },
    {
      "name": "Reinforcement bar",
      "tag": "400B and C",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": null,
      "note": "30 bars spaced as shown at midspan; 6 bars at eq. sps. at each overhang; 13 bars at equal spaces near beam 3-4 area"
    },
    {
      "name": "Reinforcement bar",
      "tag": "403B",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": 7,
      "note": "at equal spaces, in diaphragm section"
    },
    {
      "name": "Reinforcement bar",
      "tag": "402B",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": 4,
      "note": "in diaphragm section"
    },
    {
      "name": "Reinforcement bar",
      "tag": "507B",
      "shape": "bar",
      "material": "reinforcing steel",
      "count": 2,
      "note": "appears twice in diaphragm section"
    },
    {
      "name": "Plain bar",
      "tag": "",
      "shape": "circular (1\" diameter)",
      "material": "steel (plain, unreinforced)",
      "count": null,
      "note": "1\" diameter plain bar shown in diaphragm section"
    },
    {
      "name": "Drip bead",
      "tag": "",
      "shape": "triangular",
      "material": "",
      "count": 1,
      "note": "¾\" triangular drip bead, full length of bridge, typ."
    },
    {
      "name": "Construction joint",
      "tag": "",
      "shape": "",
      "material": "",
      "count": 1,
      "note": "required construction joint parallel with deck, typ."
    }
  ],
  "measurements": [
    {
      "label": "Out to out width",
      "value": "43'-7\"",
      "unit": "",
      "appliesTo": "deck slab"
    },
    {
      "label": "Gutter to gutter width",
      "value": "40'-0\"",
      "unit": "",
      "appliesTo": "deck slab"
    },
    {
      "label": "Width between beams 1-6",
      "value": "34'-0\"",
      "unit": "",
      "appliesTo": "deck slab"
    },
    {
      "label": "Half width to PGL",
      "value": "22'-0\"",
      "unit": "",
      "appliesTo": "deck cross section"
    },
    {
      "label": "Distance to lane edge",
      "value": "6'-0\"",
      "unit": "",
      "appliesTo": "deck cross section"
    },
    {
      "label": "Overhang edge dimension",
      "value": "1'-8\"",
      "unit": "",
      "appliesTo": "deck overhang (both sides)"
    },
    {
      "label": "Edge thickness",
      "value": "1 1/2\"",
      "unit": "",
      "appliesTo": "deck edge (both sides)"
    },
    {
      "label": "Slab thickness (between beams)",
      "value": "7 3/4\"",
      "unit": "",
      "appliesTo": "deck slab"
    },
    {
      "label": "Slab thickness (overhangs)",
      "value": "8\"",
      "unit": "",
      "appliesTo": "deck slab overhangs"
    },
    {
      "label": "Clear cover (top)",
      "value": "2 1/4\"",
      "unit": "",
      "appliesTo": "reinforcement clearance"
    },
    {
      "label": "Clear cover (bottom)",
      "value": "1\"",
      "unit": "",
      "appliesTo": "reinforcement clearance"
    },
    {
      "label": "'D' dimension interior beams",
      "value": "8 3/4\"",
      "unit": "",
      "appliesTo": "interior beams"
    },
    {
      "label": "'D' dimension exterior beams",
      "value": "9 1/4\"",
      "unit": "",
      "appliesTo": "exterior beams"
    },
    {
      "label": "Cross slope",
      "value": "2",
      "unit": "%",
      "appliesTo": "deck slab"
    },
    {
      "label": "Overhang bar spacing group",
      "value": "6-400B and C",
      "unit": "",
      "appliesTo": "overhang, at each end"
    },
    {
      "label": "Overhang edge offset",
      "value": "3\"",
      "unit": "",
      "appliesTo": "beam to edge spacing, typ."
    },
    {
      "label": "Beam edge distance",
      "value": "4 3/8\"",
      "unit": "",
      "appliesTo": "end overhang detail"
    },
    {
      "label": "End overhang length",
      "value": "3'-0 1/2\"",
      "unit": "",
      "appliesTo": "end overhangs"
    },
    {
      "label": "Beam spacing",
      "value": "7'-6\"",
      "unit": "",
      "appliesTo": "beam centerline spacing, repeated 5 times"
    },
    {
      "label": "Bar spacing group",
      "value": "13-400B and C",
      "unit": "",
      "appliesTo": "at equal spaces between beams 3-4"
    },
    {
      "label": "Min. spacing",
      "value": "3'-0\" MIN.",
      "unit": "",
      "appliesTo": "typical spacing near right overhang"
    },
    {
      "label": "Diaphragm bar spacing",
      "value": "5\"",
      "unit": "",
      "appliesTo": "diaphragm section, both sides"
    },
    {
      "label": "Diaphragm bar group",
      "value": "7-403B",
      "unit": "",
      "appliesTo": "at equal spaces, diaphragm"
    },
    {
      "label": "Drip bead size",
      "value": "3/4",
      "unit": "in (triangular)",
      "appliesTo": "drip bead, full length of bridge"
    },
    {
      "label": "Edge deck thickness",
      "value": "8\"",
      "unit": "",
      "appliesTo": "right side edge detail"
    },
    {
      "label": "Right edge width",
      "value": "3\"",
      "unit": "",
      "appliesTo": "right edge detail"
    }
  ],
  "notes": [
    "DIMENSION \"D\" IS MEASURED FROM TOP OF SLAB TO TOP OF BEAMS AT CENTERLINE BEARING. VARY \"D\" BETWEEN BEARINGS TO COMPENSATE FOR DEAD LOAD DEFLECTION, AND VERTICAL CURVE.",
    "MAINTAIN A CONSTANT SLAB THICKNESS OF 7 3/4\" BETWEEN BEAMS AND 8\" IN THE OVERHANGS.",
    "\"D\" = 8 3/4\" INTERIOR BEAMS",
    "\"D\" = 9 1/4\" EXTERIOR BEAMS",
    "FENCE NOT SHOWN, TYP.",
    "REQUIRED CONSTRUCTION JOINT PARALLEL WITH DECK, TYP.",
    "3/4\" TRIANGULAR DRIP BEAD FULL LENGTH OF BRIDGE, TYP.",
    "502 AT EVERY 500A, TYP.",
    "30-400B AND C SPACED AS SHOWN",
    "500A AT 6 3/4\"",
    "501 UNDER EVERY 500A",
    "13-400B AND C AT EQUAL SPACES, TYP.",
    "6-400B AND C AT EQ. SPS.",
    "7-403B AT EQUAL SPACES",
    "1\" DIAMETER PLAIN BAR"
  ],
  "labels": [
    "SECTION THRU SLAB",
    "SECTION THRU DIAPHRAGM",
    "SR 21 WB = PGL"
  ],
  "description": "This crop shows two related cross-sectional details of a precast concrete girder bridge superstructure: an overall 'Section Thru Slab' spanning six beam lines (Beam 1 through Beam 6) with full deck geometry, cross slope, overhang details, and reinforcement bar callouts (500A, 501, 502, 400B/C series); and below it a 'Section Thru Diaphragm' view showing the intermediate diaphragms cast between the bulb-tee beams with reinforcement bars (403B, 402B, 507B) and a 1\" diameter plain bar. Notes at the top define the variable haunch dimension 'D' at interior and exterior beams and specify constant slab thicknesses. This documents deck slab and diaphragm reinforcing and geometry for the bridge superstructure, part of the beam/slab framing plan sheet."
}

{
  "view": "Cross Section",
  "objects": [
    {
      "name": "PSC beam",
      "tag": "I-508",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 1,
      "note": "labeled beam in girder line"
    },
    {
      "name": "PSC beam",
      "tag": "I-509",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 1,
      "note": "labeled beam in girder line"
    },
    {
      "name": "PSC beam",
      "tag": "I-802",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 1,
      "note": "labeled beam in girder line"
    },
    {
      "name": "PSC beam",
      "tag": "I-801",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 1,
      "note": "labeled beam in girder line"
    },
    {
      "name": "beam / girder",
      "tag": "2-800",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 1,
      "note": "edge beam location, near fence side"
    },
    {
      "name": "PSC beam (unlabeled)",
      "tag": "",
      "shape": "I-girder",
      "material": "precast concrete",
      "count": 3,
      "note": "additional I-shaped beams shown without individual callouts, part of the same girder line"
    },
    {
      "name": "deck slab",
      "tag": "",
      "shape": "tapered/sloped rectangular",
      "material": "reinforced concrete",
      "count": 1,
      "note": "deck poured over beams with 2% cross slope"
    },
    {
      "name": "edge beam / barrier curb",
      "tag": "",
      "shape": "rectangular",
      "material": "reinforced concrete",
      "count": 2,
      "note": "poured flush with outside face of beam at each end"
    },
    {
      "name": "parapet/fence post support",
      "tag": "",
      "shape": "tapered vertical element",
      "material": "reinforced concrete",
      "count": 2,
      "note": "support at deck edge, fence not shown per note"
    },
    {
      "name": "bearing pad",
      "tag": "",
      "shape": "",
      "material": "",
      "count": null,
      "note": "noted as not shown in this section"
    }
  ],
  "measurements": [
    {
      "label": "edge clearance",
      "value": "2",
      "unit": "in",
      "appliesTo": "beam spacing layout, left side"
    },
    {
      "label": "edge clearance",
      "value": "2",
      "unit": "in",
      "appliesTo": "beam spacing layout, right side"
    },
    {
      "label": "beam spacing",
      "value": "8-404",
      "unit": "",
      "appliesTo": "AT EQUAL SPACES, beam spacing dimension"
    },
    {
      "label": "cross slope",
      "value": "2",
      "unit": "%",
      "appliesTo": "deck slope direction shown by arrow"
    }
  ],
  "notes": [
    "NOTE: BEARING PADS NOT SHOWN",
    "DO NOT REMOVE EDGE BEAM FORMS UNTIL 72 HOURS AFTER THE DECK POUR IS COMPLETED OR DECK REACHES 28 DAY CONCRETE STRENGTH.",
    "POUR EDGE BEAM FLUSH WITH OUTSIDE FACE OF BEAM, TYP.",
    "FENCE NOT SHOWN, TYP."
  ],
  "labels": [
    "SECTION THRU EDGE BEAM",
    "SR 21 WB = PGL",
    "I-508",
    "I-509",
    "I-802",
    "I-801",
    "2-800"
  ],
  "description": "This crop is a cross section labeled 'SECTION THRU EDGE BEAM' showing a transverse cut through a bridge superstructure with a series of precast I-shaped beams supporting a sloped deck slab, tagged individually as I-508, I-509, I-802, I-801, and 2-800. Dimensions call out 2-inch edge clearances and an '8-404' equal beam spacing, along with a 2% cross slope referenced to the SR 21 WB profile grade line (PGL). Notes address edge beam pour requirements, formwork removal timing tied to concrete strength, omission of bearing pads and fence from the drawing, and a tapered parapet/fence support element at the deck edge."
}
