| The class asks for | Unit | A reading with that name | From |
|---|---|---|---|
| LengthL | m/mm | no reading by that name | |
| WidthW | m/mm | no reading by that name | |
| HeightH | m/mm | no reading by that name | |
| Bearing CountN_brg | count | no reading by that name | |
| Rated CapacityCAP | kN/MN | no reading by that name | |
| Material TypeMAT | — | no reading by that name |
Paired on the measurement’s name only, which cannot know that three span lengths sum to the deck length. Step 3 works these out properly for every item it matches — reading every crop behind the item, deriving what the drawings imply and showing its arithmetic. This item has not had that pass yet; the button runs it for this one.
How the sheets named it
Every dimension read for it3
- 14.7.6AASHTO LRFD Section referencep12 · p12_r03
- 18AASHTO LRFD Construction Spec Sectionp12 · p12_r03
- TOverall pad thicknessp12 · p12_r09
Notes on the sheets that carry it
- p78-404 AT EQUAL SPACES
- p7FENCE NOT SHOWN, TYP.
- p7POUR EDGE BEAM FLUSH WITH OUTSIDE FACE OF BEAM, TYP.
- p7NOTE: BEARING PADS NOT SHOWN
- p7SR 21 WB = PGL
- p78", TYP.
- p72%
- p9SLAB REINFORCEMENT NOT SHOWN
- p9BEARING PADS NOT SHOWN
- p9* 1" PREFORMED JOINT FILLER
- p9BENT 2 SHOWN
- p9BENT 3 SIMILAR
- p91 1/2" CL. 3 SIDES
- p91" DIA. PLAIN BAR
- p9SILICONE SEALANT TYPE JOINT SEALER (TYPE B, C OR D)
- p9ROUND TO 1/4" R
- p9REQUIRED CONST. JOINT., TYP.
- p9SEE DETAIL "A"
- p9DO NOT REMOVE EDGE BEAM FORMS UNTIL 72 HOURS AFTER THE DECK POUR IS COMPLETED OR DECK REACHES 28 DAY CONCRETE STRENGTH.
- p9BENT 2 SHOWN, BENT 3 SIMILAR
- p91 1/2" CL., TYP.
- p9C REQ'D. CONST. JOINT
- p12ℂ BEARING PAD = ℂ BEVELED SHIM PLATE
- p12ℂ BEARING
- p12ℂ BEAM
- p12B.F.P.R.
- p12PREFORMED FOAM JOINT FILLER SHALL BE IN ACCORDANCE WITH SUB-SECTION 833.2.10 OF THE GEORGIA DOT SPECIFICATIONS.
- p12ENDWALL NOT SHOWN
- p12CL BEVELED SHIM PLATE = CL 3" DIAMETER HOLE
- p12BEARING PADS HAVE BEEN DESIGNED ACCORDING TO AASHTO LRFD BRIDGE DESIGN SPECIFICATIONS, SECTION 14.7.6 METHOD A AND SHALL BE FURNISHED IN ACCORDANCE WITH AASHTO LRFD BRIDGE CONSTRUCTION SPECIFICATIONS, SECTION 18, BEARING DEVICES.
- p121 1/2" DIAMETER SMOOTH DOWELS SHALL BE ASTM A709 GRADE 50.
- p12BENT 1 SHOWN
- p12BENT 4 SIMILAR
- p1290°-00'-00", TYP.
- p123/16" SEALING RIB, ALL AROUND
- p12C BEARING PAD = C 3" DIAMETER HOLE
- p121. BEARING PADS HAVE BEEN DESIGNED ACCORDING TO AASHTO LRFD BRIDGE DESIGN SPECIFICATIONS, SECTION 14.7.6 METHOD A AND SHALL BE FURNISHED IN ACCORDANCE WITH AASHTO LRFD BRIDGE CONSTRUCTION SPECIFICATIONS, SECTION 18, BEARING DEVICES.
- p122. 1 1/2" DIAMETER SMOOTH DOWELS SHALL BE ASTM A709 GRADE 50.
- p123. BEARING PADS SHALL BE MADE OF 60 DUROMETER HARDNESS NEOPRENE, GRADE 3 OR HIGHER [text cut off, partial]
- p12PLAN
